Getting Started
Warning:
Figure 4. Mounting the IOX Board
18
Downloaded from
Elcodis.com
electronic components distributor
Extreme care must be taken prevent damage during installation or removal. Bending the PCB is
likely to damage the J18 connector.
ZT 4901
Roundhead
Screw (x5)
ZT 5524
Flathead
Screw (x5)
Standoff (x5)
The following instructions cover the mechanical aspects of attaching a ZT 4901 IOX Board to a
ZT 5524 Processor Board. Refer to
operation.
TM
Intel® NetStructure
ZT 4901 Mezzanine Expansion Card Technical Product Specification
Ejector
Ganging Pin (x2)
Figure 4
for an exploded view of the parts involved in this
