Specifications
Figure 10. PCB Dimensions
A.6
Table 5.
30
Downloaded from Elcodis.com electronic components distributor

Connectors

As shown in Figure 11 on page
application-specific devices. A brief description of each connector is given in the table below.
Detailed connector descriptions and pinouts are given in the following topics.

Connector Assignments

Connector
J1 CompactPCI Bus Connector (110-pin, 2 mm x 2 mm, female)
J2 CompactPCI Bus Connector (110-pin, 2 mm x 2 mm, female)
J5 Rear Panel I/O Connector (110-pin, 2 mm x 2 mm, female)
Small Form-Factor Pluggable (SFP) Sockets (accept copper/optical Fibre Channel
J6, J7
modules)
J9 Reserved (10-pin, male)
J10 Board-to-Board Connector (192-pin, female)
J11, J12, and J13 PMCB Connectors (64-pin, female)
J21, J22, J23, and
PMCA Connectors (64-pin, female)
J24
TM
Intel® NetStructure ZT 4901 Mezzanine Expansion Card Technical Product Specification
233.35 mm
31, the ZT 4901 includes several connectors to interface to
Function
160.0 mm
