Table 3.
A.3
A.4
A.5
Note: When combined with the ZT 5524, the two-board complex occupies two slots.
Table 4.
Intel® NetStructure
Downloaded from Elcodis.com electronic components distributor
Absolute Maximum Ratings (Sheet 2 of 2)
Storage Temperature (hard disk):
Operating Temperature:
Non-Condensing Relative Humidity:

Thermal Requirements

The ZT 4901 can operate between +5° and approximately +55°C ambient, with a minimum of
200LFM (1 meter per second) of external airflow. External airflow must be provided to the
ZT 4901 at all times.

Reliability

MTBF: 33 years (excluding accessory devices)
MTTR: 3 minutes (based on board replacement), plus system shutdown and
startup

Dimensions

The ZT 4901 meets the CompactPCI Specification, PICMG* 2.0, Version 2.1 for all mechanical
parameters. In a CompactPCI enclosure with 0.8 inch spacing, the ZT 4901 occupies one 6U card
slot.
Mechanical dimensions are shown in

Mechanical Dimensions

Type
PCB Dimensions
Board Dimensions
Weight
Board-to-Board Centerline
Spacing from Host Carrier:
TM
ZT 4901 Mezzanine Expansion Card Technical Product Specification
-40° to +60° Celsius
+5° to +55° Celsius
<95% at 40° Celsius
Figure 10 on page 30 and are listed in the table below.
Dimension
233.35 mm x 160 mm x 1.6 mm
6U x 4HP (one slot, occupies two slots when combined with the
ZT 5524)
272.2 g (9.6 ounces) without accessory devices
0.8"
Specifications
