M500MJ
An addressable monitor module that can be used to monitor
conventional normally open contact alarm initiating devices, such as
manual pull stations, 4 - wire smoke detectors, heat detectors, waterflow,
and supervisory devices. Supervised circuit can be wired NFPA Style B
or Style D.
M502MJ
An addressable monitor module that monitors conventional 2 -wire
smoke detectors. Supervised circuits can be wired NFPA Style B or
Style D. M502MJ supervises initiating device circuit wiring,
communication loop, and input power.
M510CJ
An addressable control module that can be used as an indicating
appliance circuit for powering and supervising compatible, UL Listed
indicating appliances. Supervised circuits can be wired NFPA Style Y or
Style Z. By breaking two built -in tabs, the M510CJ can be employed as
a Form-C control relay.
M500XJ
The loop isolator module is an automatic switch that opens the circuit
voltage to a predetermined communications loop branch(es) whenever a
fault is detected on that circuit. The remainder of the communications
loop leading up to the M500XJ will continue to operate, unaffected by
the fault.
M501MJ
An addressable module that is functionally identical to an M500MJ
monitor module (Style B circuits only), but offered in a smaller package
for mounting directly in the electrical box of the device being monitored.
BGX-101L
The addressable manual pull station features a key -lock reset. The pull
station responds to an address set by the installer with built -in rotary
decimal switches. Includes key.
A2143-00
The 47K end -of-line resistor assembly is used in the supervision of
M500MJ Monitor and M510CJ Control Module circuits. It is included
with each M500MJ or M510CJ module.
