Control-by-
Detector
Table 12: Activating M510CJs Based on Detector Activity
Alarm
From
Detector
Detector
Detector
Detector
* Result is the same whether M510CJ is mapped to any zone or not.
** Result is the same regardless of M510CJ address.
General
M510CJ Trouble
Non-
Silenceable
Indicating
Appliance
Circuit
Non-
Silenceable
Form-C Relays
Supervisory
Zones
Control-by-Detector is a useful function for activating sounders in the same
room or location as the alarmed intelligent detector. To set up
Control-by-Detector, set detector address in the range 80 - 99. Ensure that
a M510CJ module exists with the same address as the detector, and that
the M510CJ has not been mapped to any zones.
Detector M510CJ Address
Address
80-99 Same as detector
80-99 Same as detector
80-99 Other than detector
1-79 **
M510CJ modules programmed for General Alarm, Control -by-Module, or
Control-by-Detector do not have a zone assignment. If a trouble occurs on
one of these devices, it is reported as trouble on Zone 1.
An M510CJ configured as an indicating appliance system (tabs intact) can
be programmed in AIM -200 memory as a Form -C module. The module
will still function as a supervised indicating appliance circuit, but will be
non-silenceable. This feature is suitable in applications that require strobe
lights to continue flashing after the signals have been silenced during an
alarm.
A M510CJ configured as a Form -C Relay (type
silenced by the SIGNAL SILENCE switch on the CPU. These modules,
regardless of their mapping assignments, can only be silenced by the
RESET switch on the CPU.
This supervisory monitoring function (tamper valves, etc.) is transparent to
the AIM-200. This programming selection is performed at the CPU.
Addressable Intelligent Module—AIM -200 Addressable Intelligent Module
M510CJ Mapped Results
to Zone(s)?
No M510CJ will be activated if it
shares the same least significant
digit with the alarmed device and
is not mapped to any zones.
Yes M510CJ will not be activated if it
shares the address of the alarmed
device but is mapped to a zone.
* M510CJ will not be activated if it
does not share the address of the
alarmed device.
* M510CJ will not be activated if the
address of the alarmed device is
not within the range of 80-99.
) cannot be
