AIM-200 Power Requirements

Use Table 2 to determine the amount of current drawn by the AIM - 200(s)
during non -alarm conditions. Place the total standby current obtained in
the Installing the FC-2000 Technical Bulletin in this document when
calculating secondary power standby requirements for the control panel.
Table 2: Standby Regulated Power Requirements
Device Type Device
Number
[
AIM-200
(Note 1)
[
Detectors and
Modules
1551J, 2551J,
2551TH,
5551J,
M500MJ,
M501MJ,
M510CJ,
BGX-101L
[
M500XJ
1. Maximum number of AIM -200s is determined by power supply
loading limits in the Installing the FC-2000 Technical Bulletin in this
manual but may never exceed the following limits: 10 with the
MPS-24A; 2 with the MPS -24B.
Use Table 3 to determine the amount of current drawn by the AIM - 200(s)
in the FC-2000 during an alarm. Place the Total Alarm Current obtained in
the Installing the FC-2000 Technical Bulletin in this manual when
calculating regulated requirements in the alarm state for the control panel.
Table 3: Alarm State Regulated Power Requirements
Device Type Device
Number
AIM-200 [
Addressable Intelligent Module—AIM -200 Addressable Intelligent Module
Current
(amps)
] X 0.050
] X 0.000210
] X 0.000420
Total Standby Current =
Current
(amps)
] X 0.075
Total AIM-200 Current (from Table 2)
Total Alarm Current =
Total Current
=
=
=
amps
Total Current
=
=
amps
41
