- Page 1 ENGINEERING MANUAL VRF Central Touchscreen Controller Engineering Manual < VRF Central Touchscreen Controller > CCXL01 < VRF Central Touchscreen Controller Adapter > CCXLA01 < Energy Calculation Software > CCSE01 TC-19001...
- Page 3 Important Notice ● Johnson Controls Inc. pursues a policy of continuing improvement in design and performance in its products. As such, Johnson Controls Inc. reserves the right to make changes at any time without prior notice. ● Johnson Controls Inc. cannot anticipate every possible circumstance that might involve a potential hazard.
-
Page 4: Safety Summary
Use only Johnson Controls recommended, provided as standardized, or replacement parts. ● Johnson Controls will not assume any liability for injuries or damage caused by not following steps outlined or described in this manual. Unauthorized modifi cations to Johnson Controls products are prohibited as they…... - Page 5 When shielded cabling is applied, proper bonding and termination of the cable shield is required as per Johnson Controls guidelines. Plenum and riser ratings for communication cables must be considered per application and local code requirements.
- Page 6 ● Use an exclusive power supply at the controller’s rated voltage. ● Be sure to install circuit breakers (ground fault interrupter, isolating switch, molded case circuit breaker, and so forth) with the specifi ed capacity. Ensure that the wiring terminals are tightened securely to recommended torque specifi...
-
Page 7: Table Of Contents
- CONTENTS - IMPORTANT NOTICE AND SAFETY SUMMARY ..............i 1. Safety Summary ........................i 1. System Summary ......................... 1-1 2. System Specifi cation ......................2-1 2.1 Features ........................2-1 2.2 Example for System Confi guration ................2-4 2.3 Standard Specifi cation ....................2-5 2.4 Appearance ........................ - Page 8 TC-19001...
-
Page 9: System Summary
SYSTEM SUMMARY Function Specifi cation Item Description VRF Central Touchscreen Controller: CCLX01 (1) Model VRF Central Touchscreen Controller Adapter: CCXLA01 *1 Energy Calculation Software: CCSE01 *2 VRF Central Touchscreen Controller: 60292274 (2) Product Code VRF Central Touchscreen Controller Adapter: 60292275 Energy Calculation Software: 60292276 H-LINK: 16 Groups: 2,048... - Page 10 SYSTEM SUMMARY Control Device 1.2.1 Line Up Refer to the illustrations below showing the VRF control system components. H-LINK II or H-LINK Cable Controller Cable Central Controllers Mini Central Controller Large Central Controller VRF Central Touchscreen Controller Outdoor Units Indoor Units Individual Remote Controllers IR Receiver Wired Controller...
- Page 11 IR(Infrared) Receiver Kit for 4-Way Cassette C4IRK01 Control IR(Infrared) Receiver Kit for 1-Way Cassette C1IRK01 Devices IR(Infrared) Receiver Kit for Wall Mounted and Ducted CWDIRK01 Mini Central Controller CCM01 Large Central Controller CCL01 VRF Central Touchscreen Controller / Adapter CCXL01/CCXLA01 TC-19001...
- Page 12 SYSTEM SUMMARY H-LINK II The H-LINK transmission system for connection between outdoor and indoor units provides an extended system confi guration and improved functions without sacrifi cing workability and fl exibility. : H-LINK II Control Wiring Outdoor Units (Max. 64 Refrigerant Group)* Indoor Units (Max.
- Page 13 SYSTEM SUMMARY System Confi guration Example (1) Individual Remote Controller Confi guration Example Below are illustrations of confi gured individual remote controllers. H-LINK II MAX. 16 Indoor Units Comm. Wiring to Zone Controller Meeting Room FLTR MODE SPEED LOUV. TEMP Avoid COOL Motion Sensor ON...
-
Page 15: System Specification
SYSTEM SPECIFICATION 2. System Specifi cation 2.1 Features (1) Management of up to 2,048 groups (2.560 indoor units)* This product alone can monitor and control air conditioners. * With 15 VRF Central Touchscreen Controller Adapters (optional) connected. (2) Touch screen LCD Newly adopted 12.1 inch wide color LCD provides user-friendly touch screen operation. - Page 16 SYSTEM SPECIFICATION ● Applicable Models As for 2017/11/28 Item Model Type JCI Model Name (H,Y)VAH(P,R)_B31S Top Flow (208/230V) Heat Pump and Heat Recovery Standard Type (H,Y)VAH(P,R)_B32S Top Flow (208/230V) (H,Y)VAH(P,R)_B31LM Heat Pump and Heat Recovery Less Module Type (H,Y)VAH(P,R)_B41S Top Flow (460V) Heat Pump and Heat Recovery Standard Type Outdoor Unit (H,Y)VAH(P,R)_B42S...
- Page 17 RC Group Group Block Area RC Group- Registered on CCXL01 as a collection of indoor units (up to 16) connected via RC control line. Group- Registered on CCXL01 as a collection of multiple RC groups altogether. Block - Registered on CCXL01 as a collection of multiple Groups altogether.
-
Page 18: Example For System Confi Guration
In this document, PIO refers to programmable logic controller with 128 input/output (dedicated extension each manufactured by Industrial Equipment Systems Co. Ltd. pulse input/output VRF Central Touchscreen Controller (CCXL01) and VRF Central Touchscreen device) Controller Adapter (CCXLA01) can monitor/control 2 PIO devices respectively. TC-19001... -
Page 19: Standard Specifi Cation
SYSTEM SPECIFICATION 2.3 Standard Specifi cation ● VRF Central Touchscreen Controller Hardware Specifi cation Item Specifi cation 14-5/8 × 8-15/16 × 1-1/4 + 1-1/8 (molded in wall) inch Dimensions (W×H×D) (372 × 227.2 × 32.5 + 27.8 (molded in wall) mm) Net Weight 7.7lbs. -
Page 20: Appearance
SYSTEM SPECIFICATION 2.4 Appearance (Unit: inch(mm)) 1-1/4 1-1/8 (32.5) (27.8) 14-5/8 (372) SD Card Slot USB flash drive slot H-LINK, External in/output Wiring Port LAN Port Power Input TC-19001... - Page 21 SYSTEM SPECIFICATION Parts Names and Functions The following diagram shows VRF Central Touchscreen Controller with front and rear cover removed. Each name and function are listed. Regarding how to connect each terminal, refer to “2.6.3 Electrical Wiring” on page 2-15. Regarding how to set each switch, refer to “2.6.4 Switch Setting Procedures” on page 2-17.
- Page 22 SYSTEM SPECIFICATION Dimension and Parts Names Dimension and parts names are as follows: ■ VRF Central Touchscreen Controller: CCXL01 (Unit: inch(mm)) 1-1/4 1-1/8 (32.5) (27.8) 14-5/8 (372) Power Indicator SD Card Slot Indicates the status of AC Run/Stop Indicator Extra Large Central Controller.
- Page 23 SYSTEM SPECIFICATION ■ VRF Central Touchscreen Controller Adapter: CCXLA01 (Unit: inch(mm)) 10-1/16 (255.6) 4-ϕ0-1/4 (ϕ6) 9-1/4 (235.6) Status Indicator Screw Hole for Wall Mount Power Button (Remove rubber cover.) H-LINK, External in/output, and LAN Wiring Port Power Line Port TC-19001...
- Page 24 © 2019 Johnson Controls, Inc. TC-19001 Code No. LIT-12013165 Issued Feb. 2019...
