Introduction

Note: AIM-200 features discussed in this document are available with
AIM-200 software part number 73264 or greater.
The Addressable Intelligent Module (AIM -200) functions as an interface
between the FC -2000 Fire Alarm Control Panel and intelligent/addressable
devices. To the FC -2000, the AIM -200 looks like an IZM -8 Initiating
Zone Module. On its single communications loop, the AIM -200 will
communicate with up to 99 addressable modules and 99 intelligent
detectors. The AIM -200 will communicate with the following:
2551J Intelligent Photoelectric Smoke Detector
1551J Intelligent Ionization Smoke Detector
5551J Intelligent Thermal Sensor
M500MJ Addressable Monitor Module
M502MJ Addressable Monitor Module
M501MJ Miniature Monitor Module
M510CJ Addressable Control Module
BGX-101L Addressable Manual Pull Station
DH-500J Intelligent Duct Detector Housing
The 198 devices are mapped into eight software zones by the AIM
The status of these zones is reported to the CPU -2000. The AIM -200
includes a digital display for identifying the exact device address within a
zone. The display is also used to display device types and analog detector
sensitivity values.
Although the AIM -200 is intended primarily as an initiating input module,
it can support M510CJ Control Modules on the loop. The M510CJ
modules may be mapped to AIM -200 zones much like outputs are mapped
to inputs during standard FC -2000 programming.
The AIM-200 may be mixed in a system with any of these system modules:
IZM-8 Initiating Zone Module
IZE-A Initiating Zone Expander
ICM-4 Indicating Circuit Module
ICE-4 Initiating Circuit Expander
CRM-4 Control Relay Module
CRE-4 Control Relay Expander
Addressable Intelligent Module—AIM -200 Addressable Intelligent Module
-200.
