Displaying the
Status of
Addressable
Modules
Device Type (Cont.)
G
Monitor Module
Monitor Module
GA
Monitor Module
GF
Monitor Module
GE
Monitor Module
Gd
Control Module (IAC)
C
Control Module (IAC)
CA
CF
Control Module (IAC)
Control Module (IAC)
CE
Control Module (IAC)
Cd
Control Module (Relay)
CO
Control Module (Relay)
CC
Control Module (Relay)
CF
Control Module (Relay)
Cd
LF
SF
EP
AP
Note: Invalid device type = "E" left digit. Maintenance Alert = "F" left
digit.
After the AIM-200 has stepped through all detectors, it will begin displaying all
modules. The digital display will repeatedly flash between the address and
type/status of the module assigned to the lowest address. The user can scroll
through all modules using the STEP-FORWARD and STEP-REVERSE
switches. The SKIP switch advances through addresses rapidly.
Module Device Type/Status
The Device Type/Status field displays two characters for modules, outlined
below.
Table 14: Device Type/Status Field Characters
Left Digit
G = Monitor Module or Pull Station
C = Control Module
Addressable Intelligent Module—AIM -200 Addressable Intelligent Module
Status
Normal
Alarm
Trouble
No answer
Disabled
Normal
Alarm output
Trouble
No answer
Disabled
Open (OFF)
Closed (ON)
Trouble
Disabled
Line Fault (Style 6)
CPU loss of communication
Enter Password
Auto-Program
Right Digit
Blank = Indicating circuit selected
A = Alarm
F = Fault--Trouble (open monitor module
zone; open or short M510CJ)
d = Disabled
O = Open (Form-C)
C = Closed (Form-C)
E = Error--No response from a device (the
AIM-200 is programmed for a device that is in
trouble or not physically installed on the loop).
57
