Inventory

AIM-200
Addressable
Intelligent Module
4 Addressable Intelligent Module—AIM -200 Addressable Intelligent Module
VCM-4 Voice Control Module
VCE-4 Voice Control Expander
DCM-4 Dual Channel Module
TCM-2 Time Control Module (Single hazard release)
TCM-4 Time Control Module (Multiple hazard release)
In addition, ACM remote annunciators, AMG - 1 and FFT-7
voice/telephone modules, and several power supplies can be employed with
an AIM-200.
Up to ten AIM-200s may be installed in one FC - 2000 for a capacity of
1,980 points (subject to limitations of system power supply). Refer to the
AIM-200 Power Requirements section of this document.
Figure 1: AIM-200 Addressable Intelligent Module
