General Alarm

Operating M510CJ Control
Modules
Optional M510CJ control modules can be installed on the AIM
addressable loop. When using one or more M510CJs, four types of control
options are available: General Alarm, Control -by-Zone,
Control-by-Module, and Control - by-Detector. The M510CJ zone mapping
and address assignments required for each control option are described
below.
To set up General Alarm, set M510CJ module address in the range of
01-59 and ensure that it has not been mapped to any zones. If an alarm
occurs on the alarm bus (see Figure 6 for wiring information), the M510CJ
will be activated. This type of control can also be executed using the
manual switch on the CPU board alarm relay (manual evacuation).
Table 9: Activating M510CJs Based on an Alarm Anywhere in the
System
Alarm M510CJ
From Address
Alarm Bus 01-59
Alarm Bus 01-59
Alarm Bus 60-99
* Result is the same whether M510CJ is mapped to any zone or not.
Addressable Intelligent Module—AIM -200 Addressable Intelligent Module
M510CJ Mapped Results
to Zone(s)?
No M510CJ will be activated if not
mapped to any zone.
Yes M510CJ will not be activated if
mapped to a zone.
* M510CJ will not be activated if not
in the address range of 01-59.
