Figure 6-11 Layer settings
Select Canvas Resolution, enable the value editing status, rotate the knob to adjust the value and press the knob to
confirm it.
Select Layer 1, press the knob to open the editing page, and set the related parameters.
Figure 6-12 Editing layer 1

Status: Turn on or off the layer.

Input: Select an input source.

Scaling Mode: Set the scaling mode.
−
Custom: Customize the width and height.
−
Pixel to Pixel: The layer width and height are the same as the input source.

Width: Set the layer width.

Height: Set the layer height.

6.6 Color Processing

This chapter describes color processing with one device selected. You can perform any of the following operations as
required.

6.6.1 Color Replacement

Replace one color with another color according to the specified settings.
This function only has an on/off switch on the CX80 Pro. You need to follow the steps below to set the specific
parameters in VMP.
Note
Replacement of highly saturated colors is recommended for better effect.
Run VMP and connect devices.
Select Processing.
