Ethernet Port Load Capacity

When the CX80 Pro works with CA50E, CA50C and XA50 receiving cards, the formula of calculating the load
capacity per Ethernet port and the detailed parameters are as follows.

8bit: Load capacity × 24 × Frame rate < 5G × 0.75

10bit: Load capacity × 30 × Frame rate < 5G × 0.75

12bit: Load capacity × 36 × Frame rate < 5G × 0.75
Max Load Capacity per Ethernet Port (Pixels)
Frame Rate / Bit Depth
24 Hz
25 Hz
30 Hz
50 Hz
60 Hz
120 Hz
144 Hz
240 Hz
www.novastar.tech
8bit
6,480,000
6,220,800
5,184,000
3,110,400
2,592,000
1,296,000
1,080,864
648,000
CX80 Pro LED Display Controller User Manual
10bit
5,182,500
4,975,200
4,146,000
2,487,600
2,073,000
1,036,500
864,441
518,250
12bit
4,320,000
4,147,200
3,456,000
2,073,600
1,728,000
864,000
720,576
432,000
