NovaStar CX80 Pro User Manual page 6

With Input Card 2 Installed
Input Cards
Input card 1: CX_HDMI 2.1+DP 1.4+12G-SDI×4
Type
HDMI 2.1
DP1.4
12G-SDI
www.novastar.tech
Qty Description
1 Resolutions
HDR
EDID management
HDCP
Interlaced signal inputs
1 Resolutions
HDR
EDID management
HDCP
Interlaced signal inputs
4 Standards
Resolutions
Frame rates
Mosaic
Interlaced signal inputs
Others
CX80 Pro LED Display Controller User Manual
7680×4320@(60/50/48/30/25/24Hz) only
Support HDR10 and comply with the SMPTE ST 2084 and
SMPTE ST 2086 standards.
Support HLG.
Support standard resolutions:
7680×4320@(60/50/48/30/25/24Hz).
Do not support custom input resolutions.
HDCP 2.3 compliant, backwards compatible
Not supported
7680×4320@(30/25/24Hz) only
Support HDR10 and comply with the SMPTE ST 2084 and
SMPTE ST 2086 standards.
Support HLG.
Support standard resolutions: 7680×4320@(30/25/24Hz).
Do not support custom input resolutions.
HDCP 2.2 compliant, backwards compatible
Not supported
Support ST-2082 (12G), ST-2081 (6G), ST-424 (3G) and
ST-292 (HD) standard video inputs.
Support 3G-Level A/Level B (DS mode).
Max resolution: 4096×2160@60Hz
Support frame rates up to 60 Hz.
SDI input sources support input mosaic.
Not supported
Belden 12G SDI standard cables are recommended.
Cables up to 50 meters are supported.
3
