NovaStar CX80 Pro User Manual page 11

Item Content
192.168.102.189
Input HDMI, DP, SDI,
Internal
Genlock 60Hz
Port 1–16
OPT 1–2
Screen 1920*1080@60Hz
www.novastar.tech
Description
The chassis fan speed

Green: The fan speed is normal.

Yellow: Fan speed alarm. The speed exceeded the threshold range.

Yellow: Fan speed alarm. The speed exceeded the threshold range
significantly.
The connection status of the Ethernet ports

White: Connected

Gray: Not connected
The device IP address
Please refer to 7.3 Set an IP Address
The device input source type and status, and the resolution and frame rate of
the currently available input source

Green: The signal is normal.

Blue: The signal is normal, but not used.

Red: The signal is abnormal.

Gray: The signal is abnormal and not used.
You can touch this area to enter the input settings page. Please refer to
Set Input Source for related operations.
The frame rate of the currently connected sync source
When sync source not connected: "No Signal" is displayed.


When sync source connected: Display the frame rate of the current sync
source.
The statuses of the Ethernet output ports

Blue: The Ethernet port connection works and the port serves as primary.

Gray: The Ethernet port is not connected or the connection does not work.

Blue with a mark (not flashing) on top corner of icon: The Ethernet port is in
backup status, but the backup has not taken effect.

Blue with a mark (flashing) on top corner of icon: The Ethernet port is in
backup status and the backup has taken effect.
You can touch this area to enter the screen settings page. Please refer to
Screen Settings for related operations.
The statuses of the OPT ports

Blue: Connected

Gray: Disconnected
The screen resolution and frame rate
CX80 Pro LED Display Controller User Manual
for related operations.
5.1
