Control Connectors
Type Qty
ETHERNET 2
GENLOCK 1
AUX 1
Power
100-240V~, 50/60Hz, 4A
Note

For input card 1, the HDMI and DP connectors support only 7680×4320 input sources. For requirements of
other resolutions, frame rates and bit depths on input card 1, please contact NovaStar for customization.

For all the input cards, the width of HDMI and DP input sources must be an integer multiple of eight. In addition,
the maximum input resolution and maximum width and height of HDMI 2.0 and DP 1.4 connectors must be
obtained by setting the graphics card.
www.novastar.tech
Description
Gigabit Ethernet control ports. Support TCP/IP protocol and star topology.
They have the same functions without priority and order, and can be connected to VMP
software. No switch or router is needed to deploy multiple devices on the same LAN via
device cascading as the network switching function is already built in. Up to 20 CX80
Pro devices can be cascaded.
A pair of Genlock signal connectors. Support Bi-Level and Tri-Level.

IN: Accept the sync signal.

LOOP: Loop the sync signal.
For standard Genlock signal generators, up to 20 CX80 Pro devices can be cascaded.
An auxiliary port that connects to the central control device (RS232) (Reserved)
An AC power input connector and switch
