Video Source Specifications

Input
Input card 1 HDMI 2.1
DP 1.4
12G-SDI
Note
Input
Input card 2 HDMI 2.0
12G-SDI
www.novastar.tech
Features
Bit Depth Color Space/Sampling
RGB4:4:4
8bit
YCbCr4:4:4
YCbCr4:2:2
RGB4:4:4
10bit/12bit
YCbCr4:4:4
YCbCr4:2:2
RGB4:4:4
8bit/10bit
YCbCr4:4:4
YCbCr4:2:2
YCbCr4:2:2
12bit
YCbCr4:2:2
10bit

For input card 1, the HDMI and DP connectors support only 7680×4320 inputs.

For requirements of other resolutions, frame rates and bit depths on input card 1,
please contact NovaStar for customization.
Features
Bit Depth Color Space/Sampling
RGB4:4:4
8bit
YCbCr4:4:4
YCbCr4:2:2
RGB4:4:4
10bit/12bit
YCbCr4:4:4
YCbCr4:2:2
10bit
CX80 Pro LED Display Controller User Manual
All Input Resolutions
7680×4320@(60/50/48/30/25/24Hz)
7680×4320@(30/25/24Hz)
7680×4320@(60/50/48/30/25/24Hz)
7680×4320@(30/25/24Hz)
7680×4320@(30/25/24Hz)
Max connector capacity 4096×2160 @60Hz
Max mosaic capacity 8192×4320@60Hz
Max Input Resolution
Max connector capacity 4096×2160 @60Hz
Max mosaic capacity 8192×4320@60Hz
Max connector capacity 4096×1080@60Hz
Max mosaic capacity 8192×2160@60Hz
Max connector capacity 4096×2160 @60Hz
Max mosaic capacity 8192×4320@60Hz
