4.6

Calibration by user

4.7

Operating data

IMT Analytics AG
Offset calibration of the pressure and flow sensors
Degree of protection, against water and dust, according to IEC 60529: IP 20
The two devices FlowMeter F1 and FlowMeter F2 have 3 different modes:
• Battery operated
• Mains supplied / battery charging
• Switched off / storage
Please note the different ambient condition for the different modes. The allowed con-
ditions for the Flow channel and the device enclosure are different.
Battery operated
Environment conditions
Temperature (flow channel / enclosure)
Air humidity (enclosure)
Air humidity (flow channel)
Absolute pressure in flow channel
Atmospheric pressure
Mains operated
Environment conditions
Temperature (flow channel / enclosure)
Air humidity (enclosure)
Air humidity (flow channel)
Absolute pressure in flow channel
Atmospheric pressure
Specifications
(6.5.7 Zero offset calibration).
Allowed range
-10 – 50 °C (14 – 122 °F)
10 % – 90 % RH*
0 % – 100 % RH*
50 kPa – 200 kPa
54 kPa – 120 kPa
Allowed range
5 – 40 °C (41 – 104 °F)
10 % – 90 % RH*
0 % – 100 % RH*
50 kPa – 200 kPa
54 kPa – 120 kPa
