9.0 MIX Mode

1. Press Back button to enter mode selection.
2. Press the Up/Down button
3. Press the Enter button
4. Use the Up/Down button
5. Press the Enter button
6. Use the Up/Down button
7. Press the Enter button
Mixing is performed automatically by pressing the Plunger button once. After mixing is complete, pressing the Plunger button will
reactivate the mixing process until the user changes the function mode.

10.0 SE (Sequential Aspirating/Dispensing) Mode

SE mode includes SA (Sequential Aspirating) mode and SD (Sequential Dispensing) mode.

10.1 SA (Sequential Aspirating) Mode

The Labnet Excel™ electronic pipettor performs repetitive aspirations of a selected volume. An air gap is created automatically between
each aspiration. When the sequential aspiration is completed, the next operation will dispense all of the aspiration volume together.
1. Press the Back button to enter function mode selection.
2. Press the Up/Down button
3. Press the Enter button
4. Use the Up/Down button
5. Press the Enter button
6. Under the COUNT symbol, 01 will appear. Press the Up/Down button
7. Press the Enter button
8. Repeat Steps 6 and 7 to set the sequential aspiration volumes. The total aspirating volume (including air gap volume) cannot
exceed the maximum volume range.
9. Press the Enter button
10. The count 01 and aspirating volume will appear on the display. The pipetting direction and speed
pipettor is ready for liquid pick-up. Press the Plunger button to aspirate the samples. "A" will appear to remind the user to create
an air gap (by pressing the Plunger button with the tip out of the sample) between sample aspirations.
11. When the aspirations are completed, the pipettor will make two beeping sounds and
for dispensing.
12. After the sequential aspirating cycle is complete and the liquid has been dispensed, press the Plunger button to reactivate the
whole cycle again until the user changes the function mode.
NOTES:
If the blow-out setting is selected, the Labnet Excel electronic pipettor will automatically blow-out the liquid during a sequential

aspiration mode.
The Sequential Aspirating (SA) function will not perform Reverse Pipetting in System (SYS) mode (even if it is selected).

repeatedly until the MIX symbol flashes.
to confirm the selection. The COUNT symbol will then appear.
to select the desired mixing count.
to confirm the selection. The default pipetting volume will flash.
to select the desired mixing volume.
to confirm the selection. The total mixing volume and counts will be displayed.
repeatedly until the SE symbol flashes.
to confirm the selection.
until the SA symbol flashes.
to confirm the selection.
to confirm the selection.
to confirm the selection.
to set the volume of the first aspiration.
will flash to indicate that the
will flash to indicate the pipettor is ready
Instruction Manual | 9
