7.0 AUTO (Automatic Pipetting) Mode

AUTO mode includes:
AUTO mode only: The Labnet Excel™ electronic pipettor performs the aspirating and dispensing of a set liquid volume.

AUTO + MIX mode: The Labnet Excel electronic pipettor performs mixing after automatic pipetting is completed. This mode is ideal

for serial dilution applications.

7.1 Setting Up the Volume in AUTO Mode Only

1. Press the Back button
mode.
2. Press the Enter button
3. Use the Up/Down button
4. Press the Enter button
TIPS:
The user can use the Plunger button instead of the Up button

To change the volume changes during pipetting, press the Enter button

to select the desired volume. Press the Enter button

7.2 Setting Up the Volume in AUTO + MIX Mode

1. Press the Back button
AUTO mode.
2. Press and hold the Enter button
pipetting volume will appear and flash.
3. Use the Up/Down button
4. Press the Enter button
5. Press the Up/Down button
6. Press the Enter button
7. Press the Up/Down button
8. Press the Enter button
Press the Plunger button to aspirate the sample. Press the Plunger button again to dispense the sample and the LCD will display the
mixing cycle count and volume. Press the Plunger to mix and dispense the sample. At the end of mixing, the sample will remain in the
tip and LCD will display bL. Press the Plunger to dispense the remaining sample using the blow-out function.

8.0 MD (Multiple Dispensing) Mode

In MD mode, the Labnet Excel electronic pipettor performs repetitive dispensing of a selected volume.
NOTE: When using Multiple Dispense (MD) mode, it is recommended to select Reverse Pipetting in the System (SYS) settings for best
results. Reverse Pipetting is used in MD mode to provide better accuracy and precision with repeated dispensing.
Reverse Pipetting means that an extra volume of liquid will be left in the tip at the end of a multiple dispensing cycle, and the display
will show to remind the user to dispense this residual volume before repeating the multiple dispense cycle.
1. Press the Back button
2. Press the Up/Down button
3. Press the Enter button
4. Use the Up/Down button
5. Press the Enter button
6. Use the Up/Down button
7. Press the Enter button
After the settings have been entered, press the Plunger button to aspirate the sample according to the pipetting volume. Then press
the Plunger button repeatedly to dispense the samples according to the pipetting count. When the last count is reached, two beeps
will indicate that the next dispense is the last, and the display will remind the user to press the Plunger button and dispense the extra
remaining amount of liquid. After completing the Multiple Dispensing cycle, press the Plunger button again to aspirate liquid into the
tip and repeat the set MD cycle.
8 | LABNET EXCEL ELECTRONIC PIPETTORS
to enter the mode selection. The AUTO symbol will flash. If not, press Up/Down button
to confirm the mode selection.
to select the desired pipetting volume.
to confirm volume. The Labnet Excel electronic pipettor is ready for pipetting.
to enter the mode selection. The symbol AUTO will flash. If not, press the Up/Down button
for 3 seconds to enter AUTO + MIX mode selection. Both AUTO and MIX symbols will appear. The
to select the desired pipetting volume.
to confirm selected volume and enter MIX mode setting. The COUNT symbol will flash.
to select the desired mixing cycle counts.
to confirm selected mixing cycle counts. The mixing volume will flash.
to select the desired mixing volume.
to confirm selected mixing volume.
to enter the mode selection.
to make the MD symbol flash.
to confirm the selection. The default pipetting volume symbol will then appear.
to select the desired pipetting volume.
to confirm volume selection. The COUNT symbol will flash.
to select the desired pipetting count.
to confirm the pipetting count. The pipetting volume will show the total aspirating volume.
to speed up the volume setting.
to select pipetting volume and use the Up/Down button
again to confirm the desired pipetting volume.
to select AUTO
to select
