- Page 1 Labnet Excel™ Single- and Multi-channel Electronic Pipettors Instruction Manual Catalog Numbers: P3600L-10 P3608L-10 P3612L-10 P3600L-20 P3608L-20 P3612L-20 P3600L-200 P3608L-200 P3612L-200 P3600L-1200 P3608L-1200 P3612L-1200...
-
Page 2: Table Of Contents
Table of Contents 7.0 AUTO (Automatic Pipetting) Mode ....8 1.0 Introduction .........1 7.1 Setting Up the Volume in AUTO Mode Only . -
Page 3: Introduction
1.0 Introduction Labnet Excel™ electronic pipettors feature an accurate and efficient, as well as ergonomic and lightweight design. Researchers can program these state-of-the-art products to conduct different pipetting tasks. More accurate and comfortable pipetting can be easily achieved without any concern of finger stress or injury. -
Page 4: Specifications
100 - 1200 ±3.0 to ±0.5 ≤0.8 to ≤0.2 NOTE: Labnet Excel™ electronic pipettor accuracy and precision specifications have been attained using Labnet pipet tips. Labnet guarantees accuracy and precision only if Labnet tips or other approved tips are used. Operation mode Automatic Pipetting (AUTO) with Mixing (MIX) option ... -
Page 5: Getting Started
(Figure 2). Close the cover of the battery compartment. Press the Reset button to power on and calibrate the Labnet Excel electronic pipettor. NOTE: After a charged battery is inserted, the Labnet Excel electronic pipettor will automatically perform a calibration routine. Figure 1. Open the Figure 2. -
Page 6: Start Pipetting
4.6 Hanger Installation The Labnet Excel™ electronic pipettor hanger can be attached to a shelf or counter using the sticker (Figure 5). The finger rest of the Labnet Excel electronic pipettor locks into the hanger and keeps the pipettor in a vertical position. -
Page 7: Overview
Lower Part Tip Fitting Figure 6. Single-channel Labnet Excel electronic pipettor overview. TIP: The plunger button (Figure 6) can be used to increase the volume and to change modes and settings the same as the Up button (Figure 7) during function mode selection and volume settings. This feature can speed up the setting process. -
Page 8: Audible Signals
2 beeps: MD/MIX/SE mode cycle or Reset routine is completed 5.2 Function Map The main menu of the Labnet Excel™ electronic pipettor includes five function modes (SYS, AUTO, MD, MIX, and SE). Each mode includes various function settings (Figure 8). Function Map... -
Page 9: Dispensing Speed
Plunger button is released. 6.5 Reverse Pipetting The automatic reverse pipetting is to reserve the final drop of sample. The Labnet Excel™ electronic pipettor will not perform reverse pipetting in MIX or SA modes. -
Page 10: Auto (Automatic Pipetting) Mode
AUTO mode only: The Labnet Excel™ electronic pipettor performs the aspirating and dispensing of a set liquid volume. AUTO + MIX mode: The Labnet Excel electronic pipettor performs mixing after automatic pipetting is completed. This mode is ideal ... -
Page 11: Mix Mode
10.1 SA (Sequential Aspirating) Mode The Labnet Excel™ electronic pipettor performs repetitive aspirations of a selected volume. An air gap is created automatically between each aspiration. When the sequential aspiration is completed, the next operation will dispense all of the aspiration volume together. -
Page 12: Sd (Sequential Dispensing) Mode
After completing the dispensing, pressing the Plunger button again will reactivate the whole cycle until the user changes the function mode. NOTE: If the blow-out setting is selected, the Labnet Excel™ electronic pipettor will automatically blow-out the liquid at the end of a sequential dispensing mode. -
Page 13: Removal Of The Lower Piston Assembly
3. Slowly pull the lower piston assembly downward until the metal cylinder lock appears (Figure 10B). 4. Lay the Labnet Excel electronic pipettor down on a flat surface. Push the metal cylinder lock downward until you hear a click sound (Figure 10C). -
Page 14: Tip Ejector Height Adjustment
Labnet electronic pipettor should be disassembled. The individual parts should be rinsed in distilled water and then air dried. It is recommended to clean the Labnet Excel electronic pipettor at regular intervals depending on how much the pipettor is used, as well as lubricating it once per year. -
Page 15: Limited Warranty
Message Cause Solution Leakage or Non-uniform wetting of the plastic tip Rinse the tip once prior to pipetting. volume too Tip is incorrectly attached Attach firmly. small Unsuitable tip Use high quality tips. Failure to Low battery Charge the battery. aspirate The lower manifold is not correctly Detach and reassemble. - Page 16 To request certificates, please contact us at www.labnetlink.com. Warranty/Disclaimer: Unless otherwise specified, all products are for research use or general laboratory use only.* Not intended for use in diagnostic or therapeutic procedures. Not for use in humans. These products are not intended to mitigate the presence of microorganisms on surfaces or in the environment, where such organisms can be deleterious to humans or the environment.
