6.2 Dispensing Speed

1. The Dispensing Speed symbol
2. Press the Up/Down button
3. Press the Enter button

6.3 Audible Signals

Refer to Section 5.1 for the definition of audible signals.
1. The Audible Signals symbol should now be flashing.
2. Press the Up/Down button
3. Press the Enter button

6.4 Blow-out

The automatic blow-out function simulates the blow-out function in manual pipettors.
NOTE: To avoid leftover droplets remaining in the tip, the blow-out setting is recommended for all protocols.
The blow-out setting will not be performed in the Reverse Pipetting setting.
1. The Blow-out symbol
2. Press the Up/Down button
3. If is selected, pressing the Enter button
pressing the Enter button
NOTE: It is important to withdraw the tip quickly from the dispensed sample vessel after dispensing if blow-out is selected, as the
piston will automatically retract a short distance. When holding the Plunger button during dispensing, the piston will travel the
distance to blow out, and remain there until the Plunger button is released.

6.5 Reverse Pipetting

The automatic reverse pipetting is to reserve the final drop of sample. The Labnet Excel™ electronic pipettor will not perform reverse
pipetting in MIX or SA modes.
1. The Reverse Pipetting symbol
2. Press the Up/Down button
3. Press the Enter button
NOTE: If Reverse Pipetting is selected, the user has to press the Plunger button one more time after pipetting to dispense the
remaining liquid during the pipetting. "rE" will appear on the LCD to remind the user to dispense the remaining liquid.

6.6 Program Storing and Recall

The memory program includes 9 storage locations (PROG 01 to 09). Your favorite operating modes with user-selected settings can be
stored to these locations for future recalls. Before setting the programs, you must have programmed operating mode (e.g., AUTO, MD
modes, etc.).
Store Operating Mode to Storage Locations
1. Complete the set up of function mode (e.g., AUTO, MD, MIX mode).
2. Press and hold the Down button
3. Press the Up/Down button
4. Press the Enter button
Recall Stored Programs from the Storage Location
1. Press the Back button to enter the function mode selection. Then, press the Up/Down button
2. Press the Enter button
3. Press the Up/Down button
4. Press the Enter button
5. Press the Plunger button to operate the Labnet Excel electronic pipettor in the selected program.
NOTE: During the recall process, the changes of other settings will not be stored.
should now be flashing.
to change the dispensing speed ( : Slowest, : Fastest).
to confirm the speed selection and move to the Audible Signals function setting.
to select the preference (
to confirm the selection and move to the Blow-out function setting.
should now be flashing.
to select the preference (
will confirm the selection and move to the PROG setting. If
will confirm the selection and move to the Reverse Pipetting setting.
should now be flashing.
to choose the preference (
to confirm the selection and move to the PROG setting.
for 3 seconds to enter PROG mode.
to select PROG number from 01 to 09.
to confirm the location selection and save the settings.
repeatedly until the PROG symbol flashes.
to select the PROG number.
to confirm the selection.
: On, : Off).
: On, : Off).
: On, : Off).
is selected,
until the SYS symbol flashes.
