POWER CORD AND PLUG MAINTENANCE / GFCI BREAKER USE / PRECAUTIONS / WIRING DIAGRAM
POWER CORD AND PLUG MAINTENANCE

Caution! Risk of electric shock.

If power cord or plug becomes damaged, replace only
with cord and plug of same type.
GFCI BREAKER USE REQUIREMENT

If NEC or your local code requires GFCI protection,
you MUST use a GFCI breaker in lieu of a GFCI
receptacle.

See illustration below.
5
LBS
CAUTION! POWER CORD AND PLUG MAINTENANCE
Risk of electric shock. If cord or plug becomes damaged,
replace only with cord and plug of same type.
CAUTION! GFCI BREAKER USE REQUIREMENT
If N.E.C. (National Electric Code) or your local code
requires GFCI (Ground Fault Circuit Interrupter) protection,
you MUST use a GFCI breaker in lieu of a GFCI receptacle.
CAUTION! TOP GLASS WEIGHT LOAD LIMIT
 To prevent sagging or breakage, do not exceed 5 LBS (2.3 KG)
weight load per top glass section (between posts and/or supports).
 To prevent scratching or marring, do not place ANY items on glass.
CAUTION! ADVERSE CONDITIONS / SPACING ISSUES
 Performance issues caused by adverse conditions are NOT warranted.
 Unit must be kept at least 15-feet from exterior doors, overhead HVAC
vents or any air curtain disruption to maintain proper temperatures.
 Unit must not be exposed to direct sunlight or any heat source.
WIRING DIAGRAM FORMAT & LOCATION
 Each case has its own wiring diagram folded & in its own packet.
 Wiring diagram placement may vary; it may be placed near ballast
box, field wiring box, raceway cover, or other related location.
CAUTION! DO NOT RELY ON THERMOMETERS OR THERMOSTATS
FOR ACTUAL PRODUCT TEMPERATURES.
 Thermometers and thermostats reflect air temperatures ONLY.
 For ACTUAL food temperatures, use a calibrated food thermometer.
PRECAUTIONS

Following are important precautions to prevent damage
to unit or merchandise.

Please read carefully!
WIRING DIAGRAM

Each case has its own wiring diagram folded and in its
own packet.

Wiring diagram placement may vary; it may be placed
near ballast box, field wiring box, raceway cover, or
other related location.
