GROCERANT™ HOT SIDES MERCHANDISER MODEL DP8HP60WD.5718B
> REAR STAINLESS STEEL LEDGE BRACKETS AND HOLDER/CONTAINER BRACKETS
> VOLLRATH® MIRAGE® INDUCTION WARMING SYSTEM
> HATCO® DRAWER WARMER WITH DIGITAL TEMPERATURE CONTROLLER.
Operating Manuals\Grocerant_Vollrath_Hatco Hot Sides Merchandiser Manual_21-20699.pub
READ AND SAVE THESE INSTRUCTIONS
INSTALLATION &
DP8HP60WD.5718B
888 E. Porter Road ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com
OPERATING
MANUAL
SCC
P/N
21-20699
Rev A Date: 11.25.2020
Advertisement
Table of Contents
Related Manuals for Structural Concepts grocerant DP8HP60WD.5718B
Summary of Contents for Structural Concepts grocerant DP8HP60WD.5718B
- Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLATION & OPERATING 21-20699 MANUAL GROCERANT™ HOT SIDES MERCHANDISER MODEL DP8HP60WD.5718B > REAR STAINLESS STEEL LEDGE BRACKETS AND HOLDER/CONTAINER BRACKETS > VOLLRATH® MIRAGE® INDUCTION WARMING SYSTEM > HATCO® DRAWER WARMER WITH DIGITAL TEMPERATURE CONTROLLER. DP8HP60WD.5718B 888 E.
-
Page 2: Table Of Contents
TABLE OF CONTENTS OVERVIEW / TEMPERATURE SETTINGS / TYPE / COMPLIANCE / WARNINGS ..…..…………..POWER CORD AND PLUG MAINTENANCE / PRECAUTIONS / WIRING DIAGRAM ...…………..….. SKID REMOVAL: REMOVE FRONT & REAR TOE-KICKS / DISCONNECT CASE FROM SKID ……..SKID REMOVAL, CONT’D: REMOVAL FROM SKID / POSITIONING CASE ALONGSIDE OTHERS INSTALLATION: FIELD SERVICE ELECTRICAL CONNECTION GUIDE ..……………………..……..…. -
Page 3: Overview / Temperature Settings / Type / Compliance / Warnings
OVERVIEW This unit is designed for the display of products in ambient store Structural Concepts® Grocerant™ Hot Sides Merchandiser conditions where temperatures and humidity are maintained should be installed and operated according to this operating within a specific range. -
Page 4: Power Cord And Plug Maintenance / Precautions / Wiring Diagram
POWER CORD AND PLUG MAINTENANCE / GFCI BREAKER USE / PRECAUTIONS / WIRING DIAGRAM POWER CORD AND PLUG MAINTENANCE PRECAUTIONS Caution! Risk of electric shock. Following are important precautions to prevent damage to unit or merchandise. If power cord or plug becomes damaged, replace only ... -
Page 5: Skid Removal: Remove Front & Rear Toe-Kicks / Disconnect Case From Skid
SKID REMOVAL: REMOVE FRONT & REAR TOE-KICKS / DISCONNECT CASE FROM SKID 1. Remove Front and Rear Toe-Kicks 2. Disconnect Case From Skid Case Front: Case front toe-kicks are attached to Remove screws that are securing case to skid. case via magnets. -
Page 6: Skid Removal, Cont'd: Removal From Skid / Positioning Case Alongside Others
SKID REMOVAL, CONT’D: REMOVE CASE FROM SKID / POSITIONING CASE ALONGSIDE OTHERS 3. Remove Case From Skid 4. Position & Align Case Alongside Others Support case to prevent tipping. Before shimming frame support rails, make Caution! Rails can be damaged if case hits floor certain that the case (or cases) are in proper with heavy force! position and, if required, aligned with adjoining... -
Page 7: Installation: Field Service Electrical Connection Guide
INSTALLATION: FIELD SERVICE ELECTRICAL CONNECTION GUIDE Important! Circuit Allocation: 1. Field Access Boxes / Voltage & Amp Req. > Circuit #1 = Heat Remove front toe-kick to access field access box. > Circuit #2 = Lights See illustration below. ... -
Page 8: Case
INSTALLATION, CONT’D: SHIM / ATTACH SPLASH GUARD BRACKET AND REAR TOE-KICK TO CASE After case has been properly positioned and 2. Shim Frame Support Rails As Needed frame support rails have been shimmed, place a Shims are provided with case shipment. bead of silicone sealant to underside of splash ... -
Page 9: Installation, Cont'd: Attach Ledge Brackets And Holder/Container
INSTALLATION, CONT’D: ATTACH LEDGE BRACKETS AND HOLDER/CONTAINER BRACKETS 5. Place Ledge Brackets Onto Holders Ledge brackets are to attach to holders (at case rear near counter top). Check that brackets are held securely. 6. Attach Holder/Container Brackets Holder/container brackets attach to ledge brackets (top bracketry) and to each other. -
Page 10: Led Style Light Fixtures / Field Access Box / Led Driver
LED Style Light Fixtures Removal of lamp: Certain cases have LED lights. LED lights rarely require change-out. Should malfunction occur, contact Structural Concepts’ Technical Service Department for replacement parts. See Technical Service section of manual information. Plug Replacement of lamp: ... -
Page 11: Model Dp8Hp60Wd.5718B Overview / Vollrath® Warming System / Hatco® Heated
MODEL DP8HP60WD.5718B OVERVIEW / VOLLRATH® WARMING SYSTEM / HATCO® HEATED DRAWER 1. Model DP8HP60WD.5718B Overview Caution! If heated surface temperature is higher or lower than specified, it can result in product See illustrated breakdown below for components. temperatures outside proper range! ... -
Page 12: Vollrath® Induction Warming System: Important Safety Instructions
May 6th, 2020 Dated Documentation. Information Regarding Vollrath® Induction Drop-In Warmers Is Provided Herein As A Courtesy Of Structural Concepts Corporation For its Customers. For Vollrath’s® Latest Operating Instructions, See Page 4 Of This 4-Page Document For The Latest Vollrath® Contact Information. -
Page 13: Vollrath® Induction Warming System: Control Features
VOLLRATH® INDUCTION WARMING SYSTEM: OPERATOR’S MANUAL INFORMATION - PAGE 2 OF 4... -
Page 14: Vollrath® Induction Warming System: Operating Instructions
VOLLRATH® INDUCTION WARMING SYSTEM: OPERATOR’S MANUAL INFORMATION - PAGE 3 OF 4... -
Page 15: Temperature Control Mode
VOLLRATH® INDUCTION WARMING SYSTEM: OPERATOR’S MANUAL INFORMATION - PAGE 4 OF 4 The Vollrath Company, L.L.C. Headquarters, 1236 North 18th Street, Sheboygan, Wisconsin 53081-3201 USA ||| Main Tel: 800-624-2051 or 920-457- 4851 ||| Main Fax: 800-752-5620 or 920-459-6573 ||| Canada Customer Service: 800-695-8560 ||| Tech Services: TechServiceReps@Vollrathco.com... -
Page 16: Additional Informoation / Model
HATCO® HEATED DRAWERS: ON/OFF SWITCH / TEMP. CONTROL DIALS / ADD’L INFO / MODEL Merchandiser Start-Up and Operation Consult the full Hatco® Drawer Warmers HDW and HDW-B Series Installation and Operating 1. Hatco® Heated Drawer On/Off Switch Control Manual for complete information. ... -
Page 17: Hatco® Heated Drawers: Important Safety Instructions
HATCO® HEATED DRAWERS: IMPORTANT SAFETY INFORMATION... -
Page 18: Hatco® Heated Drawers: Model Description
HATCO® HEATED DRAWERS: MODEL DESCRIPTION / MODEL DESIGNATION All Models Hatco Heated Drawer Models >> SCC Model DP8HP60WD.5718B uses one (1) Hatco® Drawer Warmer Model No. HDW-1B / 120V. >> Illustration below may not reflect every feature or option of your particular unit. -
Page 19: Hatco® Heated Drawers: Operation
HATCO® HEATED DRAWERS: OPERATION Digital Temperature Controller Recommended Settings Chart Power ON/OFF Switch... -
Page 20: Hatco® Heated Drawers: Maintenance And Cleaning
HATCO® HEATED DRAWERS: MAINTENANCE AND CLEANING... -
Page 21: Hatco® Heated Drawers: Digital Temperature Controller
HATCO® HEATED DRAWERS: DIGITAL TEMPERATURE CONTROLLER DIGITAL TEMPERATURE CONTROLLER Note: This Information Culled From Hatco® Form No. HDWM-1218... - Page 22 HATCO® HEATED DRAWERS: DIGITAL TEMPERATURE CONTROLLER, CONT’D DIGITAL TEMPERATURE CONTROLLER, CONT’D Note: This Information Culled From Hatco® Form No. HDWM-1218...
- Page 23 HATCO® HEATED DRAWERS: DIGITAL TEMPERATURE CONTROLLER, CONT’D DIGITAL TEMPERATURE CONTROLLER, CONT’D...
-
Page 24: Hatco® Heated Drawers: Options And Accessories
HATCO® HEATED DRAWERS: OPTIONS AND ACCESSORIES OPTIONS AND ACCESSORIES... -
Page 25: Hatco® Heated Drawers: Troubleshooting Guide
HATCO® HEATED DRAWERS: TROUBLESHOOTING GUIDE... - Page 26 HATCO® HEATED DRAWERS: TROUBLESHOOTING GUIDE, CONT’D TROUBLESHOOTING GUIDE, CONT’D...
- Page 27 CLEANING & MAINTENANCE of NATURAL QUARTZ (AND OTHER STONE) SURFACES Routine For Daily, Routine Cleaning: Care Natural quartz (and other stone) surfaces require very little maintenance. Simply wipe surfaces with soap and warm water on a regular basis to maintain its shine. Any pH balanced general-purpose household cleaner may be used.
-
Page 28: Non-Heated Surface Cleaning Schedule ("D" = Daily / "W" = Weekly / "M" = Monthly)
NON-HEATED SURFACE CLEANING SCHEDULE (“D” = Daily / “W” = Weekly / “M” = Monthly) > This sheet pertains to cleaning the merchandiser in non-heated areas only. Cleaning Task Sides / Front / Toe-Kicks / Wipe off all external surfaces with warm water and mild soap solution and Bumpers, Rear non-abrasive cloth. -
Page 29: Personnel
Contact store management to have trained service provider perform troubleshooting. If case light still do not come on, it may need to be replaced. Contact Structural Concepts’ Technical Service Department for replacement light (see TECHNICAL SERVICE section of this manual for contact information). ... -
Page 30: Service Providers Only
TROUBLESHOOTING (GENERAL CASE OPERATION) - TRAINED SERVICE PROVIDERS ONLY CONDITION TROUBLESHOOTING System Is Not Operating Check that the utility power is on. Check the circuit breaker box for tripped circuits. -
Page 31: Serial Label Location & Information Listed / Technical Info & Service
For additional technical information and service, see the TECHNICAL SERVICE page in this manual for instructions on contacting Structural Concepts’ Technical Service Department. See images below for samples of both refrigerated and non-refrigerated serial labels. ... -
Page 32: Technical Service Contact Information & Warranty Information
DAMAGE, STORE’S AMBIENT CONDITIONS, ETC.) LIMITED WARRANTY Overview: All sales by Structural Concepts Corporation (hereafter referred to as “SCC”) are subject to the following limited warranty. “Goods” refers to the product or products being sold by SCC. Warranty Scope: Warranty is for equipment sold in the United States, Canada, Mexico and Puerto Rico. Equipment sold elsewhere may carry modified warranties. - Page 33 20-16052 APPROVALS, ROUTINGS & REVISIONS FORM FOR INST & OPER MANUAL DATE DUE / COMMENTS: DESCRIPTION: WORK ORDER / SEQ No. MODEL(S) PART No. SIZE(S) COMMENTS ROUTINGS / SIGNOFF ROUTED TO: DEPARTMENT INITIALS DATE COMMENTS JON MURRAY REGULAT. COMPLIANCE BK JP BD RW KL MB REFRIG.
