READ AND SAVE THESE INSTRUCTIONS
INSTALLATION &
OPERATING MANUAL
SCC P/N 20-98713
Grocerant™ Food Bars: Hatco® Manual or Auto-Fill Heated Wells / Alto-Shaam® Dry Heated
Buffet Wells / Stainless Steel Service Glass / Heated Canopy With Ceramic Heaters /
LED Lights / Rear Sanalite® Work Surfaces / Solid Quartz Surface
Model
FB9S-6HO.7355
With Hatco®
Heated Wells
Shown At Left
Model FB5S-3HO
With Alto-Shaam®
Heated Wells
Shown At Right
888 E. Porter Road ∙ Muskegon, MI 49441 Phone: 231.798.8888 Fax: 231.798.4960 www.structuralconcepts.com
Oper Manuals\Grocerant_Food Bar_V2_Auto-Fill Htd Wells_Overhead Htd Canopy_LEDs_20-75996.pub
Rev B Date: 3.12.2019
