HunterDouglas PowerView Gen 3 Automation Manual page 34

TROUBLESHOOTING
Problem Rechargeable battery needs recharging (continued)
Solution Recharging Via the Single Charger
Remove the rechargeable battery wand
from the mount, or insert the single
charger cable without removing from
the shading.
Attach the plug adapter to the charger.
■
Attach the female end of the charging cable to the
■
charger, and the male end to the battery wand. If
additional length is required to reach the battery,
attach additional charging cables as needed.
Insert and twist cables together to ensure they do not accidentally become
■
unplugged during charging.
Plug the charger into a standard AC outlet.
■
Plug the charging cable into the charging
■
outlet on the rechargeable battery wand. The
charging outlet is near the nose of the wand.
A red light indicator confirms the battery wand
■
is properly inserted and is charging.
CAUTION: Do not attempt to plug the charging cable into the battery mount's
power socket. Doing so will not only fail to charge the battery wand but could
possibly cause damage to both the single charger and the battery mount.
Once the battery has been fully recharged, the red light indicator will turn
■
green. Charging may take up to two hours, depending on your battery level.
Remove the charging cable from the battery wand.
■
(Continued on next page.)
32
Single
Charger
3 ft
charging
cable
Rechargeable
Battery Wand
Single
Charger
3 ft
charging
cable
charging
12 ft
charging
cable
Rechargeable
Battery Wand
15 ft
cable
Not this
socket
