HunterDouglas PowerView Gen 3 Automation Manual page 23

#3 — Attach the Bracket
Drill the pilot hole using a
■
using the screw provided.
IMPORTANT: Do not over torque the screw.
#4 — Install the Bracket Cover
Slide the bracket cover over the magnetic hold-down bracket and mark the screw hole.
■
Remove the bracket cover once the screw hole is marked.
■
Drill the pilot hole using a
■
and slide the bracket cover back over the
magnetic hold-down bracket.
Attach the cover using the screw provided.
■
IMPORTANT: Do not overtighten the screw.
#5 — Place and Attach Second Bracket
Repeat steps 1 through 4 to install the second magnetic
■
hold-down bracket.
IMPORTANT: Make sure the bottom rail is level when marking
the second bracket location.
#6 — Final Adjustments
Verify that the bottom rail is level.
■
"Operating the PowerView App and Gen 3 Remote" on page 22.
∕ " drill bit and attach the bracket
3
32
∕ " drill bit
3
32
Proceed to
INSTALLATION
21
