Shut the cover of the Mistral
●
Put the filter-unit housing on top of the carbon housing. The sealing should not be damaged!
●
Close the cover and lock the tension closing device.
●
Connect the Mistral again with the electricity mains.
●
Reset the failure announcement: To cancel the failure signal, push the keys + and – at the same
time for about 3 sec till the failure message disappears (display shows coal O.K.).
8.4.4.

Exchange of the brushes

With the Mistral with AC turbine appears after 450 hours:
„change brushes".
●
Switch off the Mistral at the transparency keyboard with the key
Alternatively switch off the machine which can be exhausted. After the adjusted time the Mistral is
switched off automatically.
●
Secure the Mistral against unexpected restarting by:
– disconnect the mains cable from the power supply main.
●
Loosen the tension closing device between the activated carbon filter unit and the housing of the
turbine.
●
Lift the filter device off the housing and put it aside.
●
Pull the male spade from the mains cable off the flat pin from the old carbon brushes.
●
Pull out the carbon brushes by pressing down the re-hooks.
●
Push in the new carbon brushes up to re-hook.
●
Pin the male spade of the mains cable onto the flat pin of the new carbon brush conductor.
●
Set the filter housing again on top of the turbine case and hook in the tension closing device.
●
Connect the Mistral with the electricity mains again.
●
Reset the failure announcement: To cancel the failure signal, push the keys + and ENTER at the
same time for about 3 sec till the failure message disappears (display shows brushes O.K.).
Warning!
High voltage!
Work within the electrical range may be implemented by authorised specialists only! Consider data on the
identification plate!
