All electrical construction units carry the CE characteristic for low-voltage and/or EMV.
For the grounding of the Mistral a potential equalisation (Ø > 1.5 mm²) of all leading components is installed.
The Mistral is implemented according to the type of protection IP 54.
All connections of the control and the gas-prominent hoses are clearly characterised. Electrical connection
diagrams with associated parts lists are to be found in the appendix.
3.6.

Technical data

3.6.1.

Mistral and Mistral Eco

Filtering device:
Housing:
Surrounding:
Data
Mistral 230:
Mistral Eco 230:
Mistral 110:
Mistral Eco 110:
Filter material
Filter-unit:
Activated carbon:
Pre-filter mat for activated carbon:
Mistral and Mistral ECO
Breadth
Width
Dept
Surrounding temperature, perm.+ 5 °C bis + 35 °C
Relative air humidity
Maximum air flow
Power of the motor
Connection voltage
Maximum negative pressure
Maximum air flow
Power of the motor
Connection voltage
Maximum negative pressure
Maximum air flow
Power of the motor
Connection voltage
Maximum negative pressure
Maximum air flow
Power of the motor
Connection voltage
Maximum negative pressure
Filter classification
13,5 kg
Filter classification
365 mm
1089 mm
681 mm
max. 65 %
280 m 3 /h
1,1 kW
230 V / 50/60 Hz
14.000 Pa
330 m 3 /h
1,2 kW
230 V / 50/60 Hz
14.000 Pa
280 m 3 /h
1,2 kW
110 V / 50/60 Hz
21.000 Pa
330 m 3 /h
1,2 kW
110 V / 50/60 Hz
14.000 Pa
F 9
G4
