Filter Pollution; Pre-Filter; Filter Unit; Activated Carbon - Teka Mistral Plus Operating Instructions Manual

7.

Filter pollution

7.1.

Pre-filter

Due to the large storage capability of the filter-unit the Mistral is operated in principle without a pre-filter mat.
7.2.

Filter unit

During the operation of the Mistral the percentage figure for the filter pollution (left percentage figure in the
plain text announcement) must be controlled regularly and the filter-unit must be exchanged at the latest with
a percentage figure of 100 %.
Warning!
Destruction of the filter-unit!
Destruction of the turbine. If the turbine(s) are dirty no warranty claim is given!
Possibility of direct skin contact or the inhalation of the dust!
If it is not noted that the filter pollution amounts to 100 %, it can come to tearing of the filter paper in the
housing of the filter-unit.
If the degree of pollution (left percentage figure in the plain language announcement) already indicates a
strong contamination (95 - 100 %) and afterwards indicates a smaller percentage the possibility exists that
the filter paper contained in the filter-unit tore.
In this case the Mistral has to be stopped immediately, because it can come to a damage of the turbine(s).
Call the service department of the Trotec Produktions- u. Vertriebs GmbH!
Exchange the filter-unit at once!
If "filter full" is announced, though the filter is new, the measuring hose must be controlled whether it is e.g.
broken or clogged.
7.3.

Activated carbon

The activated carbon must be changed after a certain time (1000 h are pre-set). With reaching the buzzer
sounds, the red control light shines and the plain language announcement reads "change coal".
Warning!
Possibility of the direct skin contact or the inhalation of the dust!
If it is not noted that the carbon is to change, there can be separated no more all gases and smokes.
In this case the operation of the Mistral has to be stopped as fast as possible, since it can come to an
endangerment of the health.
Speak immediately with the service department of the Trotec Produktions- u. Vertriebs GmbH!
Exchange the activated carbon at once!
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10 Page 29 of 47
