3.2.

Overview Mistral (Eco) (Super) Plus

Illustration 1: Total view
Pos.1 Transparent announcement, transparency keyboard
Pos.2 Covering
Pos.3 Filter casing
Pos.4 Activated carbon casing
Pos.5 Turbine casing
Pos.6 Guiding roller
Pos.7 Guiding roller with brake
Pos.8 Handle
Pos.9 Frame (empty)
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10
Pos.10 Filter unit
Pos.11 Activated carbon
Pos.12 Tension close device
Pos.13 2x Extraction tube NW50
Pos.14 Extraction tube NW71
Pos.15 Exit grille
Pos.16 Sub-D9 connection
Pos.17 Mains connection
Page 16 of 47
