6.3.

Operation

The operation of the Mistral takes place at its clear view control panel with plain language announcement.
Here are all functions of the Mistrals can be adjusted.
Illustration 3: Clear view control panel with plain language announcement
When switching on the plain language announcement the basic adjustment is indicated:
–
On the left the current filter pollution in per cent,
–
In the centre the operation hours passed so far,
–
On the right the current adjusted number of revolutions of the turbine in per cent (from the
maximum number of revolutions). The minimum value is adjusted to 20 %.
You will find the following control elements at the clear view control panel:
Key ON/OFF
The key ON/OFF serves for switching the Mistral on and/or off. When switching on push the key for about 0,5
sec, the turbine starts audibly and the sucking of the gas/or of the smoke begins
If you change the values (e.g. the number of revolutions of the turbines), then these attitudes are stored when
switching off. After restarting the Mistral keeps running with these attitudes.
Key ENTER
With this key you arrive the submenu which shows the system-parameter.
By pushing the key ENTER you reach the next parameter. After the last point the standard announcement
reappears.
The announcement recedes automatically to the basic announcement, if several Minutes no entries are
made.
Never attempt to change the adjustment settings without specific authorisation.
