Mistral Plus, Mistral Eco Plus And Mistral Super Plus; Differential Pressure - Teka Mistral Plus Operating Instructions Manual

3.6.2.

Mistral Plus, Mistral Eco Plus and Mistral Super Plus

Filtering device:
Housing:
Surrounding:
Data
Mistral Plus 230:
Mistral Eco Plus 230:
Mistral Plus 110:
Mistral Eco Plus 110:
Mistral Eco Super Plus 230:
Mistral Eco Super Plus 110:
Filter material
Filter-unit:
Activated carbon:
Pre-filter mat for activated carbon:
3.7.

Differential pressure

Mistral with 1 turbine and the PreFilter
Mistral with two turbines and the PreFilter
Operating Instructions Mistral (Plus), Mistral Eco (Plus), Mistral Super Plus 110 and 230V vers. 4.10
Mistral Plus, Mistral ECO Plus, Mistral Super Plus
Breadth
Width
Dept
Surrounding temperature, perm. + 5 °C bis + 35 °C
Relative air humidity
Maximum air flow
Power of the motor
Connection voltage
Maximum negative pressure
Maximum air flow
Power of the motor
Connection voltage
Maximum negative pressure
Maximum air flow
Power of the motor
Connection voltage
Maximum negative pressure
Maximum air flow
Power of the motor
Connection voltage
Maximum negative pressure
Maximum air flow
Power of the motor
Connection voltage
Maximum negative pressure
Maximum air flow
Power of the motor
Connection voltage
Maximum negative pressure
Filter classification
27 kg
Filter classification
Unit
Mistral with 1 turbine
Mistral with two turbines
Pa
2500
3500
3200
5000
365 mm
1240 mm
681 mm
max. 65 %
280 m 3 /h
1,1 kW
230 V / 50/60Hz
21000 Pa
330 m 3 /h
1,2 kW
230 V / 50/60 Hz
14.000 Pa
280 m 3 /h
1,2 kW
110 V / 50/60 Hz
21.000 Pa
330 m 3 /h
1,2 kW
110 V / 50/60 Hz
14.000 Pa
640 m 3 /h
2,4 kW
230 V / 50/60 Hz
14.000 Pa
640 m 3 /h
2,4 kW
110 V / 50/60 Hz
14.000 Pa
F 9
G4
