2-D Laser Scanner
Operation
Changing Count Parameters
Menu display
Top row
Bottom row
Underlined parameter
value
Operation
Changing Numerical Parameters
Menu display
Top row
Bottom row
Underlined parameter
value
Operation
Confirm menu
Top row
Bottom row
"Save" action
"Edit" action
"Cancel" action
IP Configuration Display
Menu display
Top row
Bottom row
This shows the current parameter.
This shows the currently selected parameter value.
This is the currently activated value.
Takes you to the next available parameter value.
Keep the button pressed for > 1 second to go to the next
menu element up without changing the parameter.
Activates the parameter value currently displayed.
Keep the button pressed for > 1 second to activate the
displayed parameter and return to the higher-level menu
element.
This shows the name of the displayed parameter.
This shows the current value of the parameter.
This is the parameter value to be edited.
Increase the currently selected digit.
Keep the button pressed for > 1 second to increase the
selected digit at a quicker rate.
Takes you to the next editable digit.
Keep the button pressed for > 1 second to go to the
Confirm menu.
This shows the changed number.
This shows the executable actions (Save, Edit, Cancel).
The changed value is applied and saved.
Takes you back to the edit display.
Rejects the changes and takes you to the higher-level
menu.
Name of the displayed parameter.
This shows the current value of the parameter.
