2-D Laser Scanner
Product Description
Figure 4.2
1
2
3
4
MultiPort
An 8-pin M12 connector is located on the rear of the housing. Inputs/outputs 3
and 4 are located here
1
2
3
4
5
6
7
8
All pins with "DNC (Do not connect)" must not be connected!
Interface:
There is a 4-pin M12 socket on the back of the housing to connect the Ethernet
interface. The following diagram shows the pinning:
12
1
2
3
Power supply connection layout
24 V power supply
I/Q2
Ground (GND)
I/Q1
1
8
2
3
4
DNC (Do not connect)
DNC (Do not connect)
DNC (Do not connect)
I/Q3
I/Q4
I/Q2
I/Q1
DNC (Do not connect)
4
7
6
5
