Product Description
Note
Influence of Ambient Conditions
The speed of light depends on the air temperature and barometric pressure.
The influence of the air temperature amounts to 1 ppm/K.
The influence of the barometric pressure amounts to -0.3 ppm/hPa.
These faults must be taken into consideration by the user in the case of longer
distances.
In the operating range (-10 °C ... +50 °C) this fault amounts to 0.6 mm at a
distance of 10 m.
4.3

Indicators and Operating Controls

7
6
5
Figure 4.1
No.
1
2
3
4
5
6
7
8
9
Table 4.1
4.4

Interfaces and Connections

The following connections are found on all devices:
Power Supply
There is a 4-pin M12 connector on the rear of the housing to connect the power
supply. The following diagram shows the pinning:
1
2
3
4
Indicators and Controls
Designation
Operating status indicator
Error indicator
"Next" menu button
"Return" menu button
Q2—input/output 2
Q1—input/output 1
Laser face
Ethernet activity indicator
Ethernet link indicator
Indicators and Operating Controls
8
9
Color
Green
Red
Yellow
Yellow
Yellow
Green
11
