Tadiran Telecom T48G/S User Manual page 8

Hardware component instructions of the T48G/S IP phone are:
Item
① Power Indicator LED
②
Touch Screen
③ HEADSET Key
④
MUTE Key
⑤
HOLD Key
⑥ TRANSFER Key
⑦
Speakerphone Key
⑧ MESSAGE Key
⑨
REDIAL Key
⑩
⑪ Volume Key
⑫ Keypad
⑬
Speaker
⑭
Hookswitch Tab
⑮ Hookswitch
Indicates phone power and some feature statuses.
The screen is touch-sensitive. Tap to select and highlight
screen items.
Shows information about calls, messages, soft keys,
time, date and other relevant data:
• Call information—caller ID, call duration
• Icons (for example,
• Missed call text or second incoming caller information
• Prompt text (for example, "Saving config file！")
• Time and date
Toggles and indicates the headset mode.
Toggles and indicates mute feature.
Places a call on hold or resumes a held call.
Transfers a call to another party.
Toggles the hands-free speakerphone mode.
Accesses voice messages.
Redials a previously dialed number.
Position the cursor within text you're updating.
Enable or disable fields.
Turn pages or scroll through values for a field.
Scroll through items.
Confirms actions or answers incoming calls.
Cancels actions or rejects incoming calls.
Adjusts the volume of the handset, headset,
speakerphone and ringer.
Provides the digits, letters and special characters in
context-sensitive applications.
Provides ringer and hands-free (speakerphone) audio
output.
Secures the handset in the handset cradle when the IP
phone is mounted vertically. For more information on
how to adjust the hookswitch tab, refer to
Mount Quick Installation Guide for T4X IP Phones
Picking up the handset from the handset cradle, the
hookswitch bounces and the phone connects to the line,
laying the handset down on the handset cradle, the
phone disconnects from the line.
Description
)
Tadiran Wall
Overview
.
2
