STEP 6. (Refer to Fig.6) Unlatch the two Lift & Turn latches at the rear of the Upper Cabinet and pivot the Mirror Shroud all the way
out.
• With the Mirror Shroud held at the maximum out position, re-latch the Lift & Turn latches.
STEP 7. (Refer to Fig.7) Attach auxiliary Electronic Equipment (optional) to the Rack Mount Rails located behind the Hinged Side
Grills.
FIG.6
FIG.7
ELECTRONIC
EQUIPMENT
(rack mounted type)
HINGED SIDE GRILL
(open position)
LIFT & TURN
MIRROR SHROUD
LATCH.
