  • Page 1 Projector A201U-B Installation Manual Model No. XP-A201U-B...
  • Page 2 Table of Contents Introduction .............................. iv Important Information ........................v 1. Check the product overview, supplied items and part names ........1 1-1. Introduction to the Projector ......................1 1-2. What’s in the Box? ..........................3 1-3. Part Names of the Projector ......................4 1-4.
  • Page 3 Table of Contents 4. Multi-Screen Projection ........................ 61 4-1. Things that can be done using multi-screen projection ............61 4-2. Using a single projector to project two types of videos at the same time [PIP/ PICTURE BY PICTURE] .......................... 62 4-3.
  • Page 4 Table of Contents 9. Appendix ............................162 9-1. Throw distance and screen size ....................162 9-2. Compatible Input Signal List ......................168 9-3. Specifications ............................ 171 9-4. Cabinet Dimensions ........................174 9-5. Pin assignments and signal names of main connectors ............ 175 9-6.
  • Page 5 Introduction Thank you for purchasing the projector. This projector can be connected to computers, video devices, etc. to project images sharply onto a screen. Please read this manual carefully before using your projector. Read this manual if you have any doubts about operation or if you believe the projector may be faulty. NOTES (1) The contents of this manual may not be reprinted in part or whole without permission.
  • Page 6 Important Information Supplier’s Declaration of Conformity SHARP PROJECTOR, XP-A201U-B This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 7 Important Information (For Customers in U.K.) IMPORTANT • The wires in this mains lead are coloured in accordance with the following code: GREEN-AND-YELLOW: “Earth” BLUE: “Neutral” BROWN: “Live” • As the colours of the wires in the mains lead of this apparatus may not correspond with the coloured markings identifying the terminals in your plug proceed as follows: •...
  • Page 8 Important Information Information on the Disposal of this Equipment and its Batteries IF YOU WISH TO DISPOSE OF THIS EQUIPMENT OR ITS BATTERIES, DO NOT USE THE ORDINARY WASTE BIN, AND DO NOT PUT THEM INTO A FIREPLACE! Used electrical and electronic equipment and batteries should always be collected and treated SEPARATELY in accordance with local law.
  • Page 9 Important Information About the symbols To ensure safe and proper use of the product, this manual uses a number of symbols to prevent injury to you and others as well as damage to property. The symbols and their meanings are described below. Be sure to understand them thoroughly before reading this manual.
  • Page 10 Important Information Safety Cautions WARNING Projected light Projected light and the pictogram/label indicated on the cabinet • Do not look into the projector’s lens. Strong light that could damage your vision is projected when the projec- tor is operating. Laser energy exposure near aperture may cause burns. Be PROHIBITED especially careful when children are around.
  • Page 11 Important Information WARNING • The following labels are stuck on the projector. Label 2 Label 1 Label 1 Label 2 Lamp warning/Laser explanatory Label FDA certification label Continue to next page...
  • Page 12 Important Information WARNING • This projector is classified as risk group 3 of IEC/EN 62471-5:2015. This projector is intended for professional use and must be installed by pro- fessional installer to ensure safety. See page for risk groups. • See page for Laser Safety Caution.
  • Page 13 Important Information WARNING • Handle the power cord with care. Damaging the cord could lead to fire or electric shock. - Do not place heavy objects on the cord. HAZARDOUS - Do not place the cord under the projector. VOLTAGE - Do not cover the cord with a rug, etc.
  • Page 14 Important Information WARNING Installing suspended from the ceiling • Consult your dealer for installing the projector on the ceiling or suspended from the ceiling using eye bolts. Special skills are required for ceiling instal- lation. CAUTION DO NOT perform installation work by people other than installers. Doing so may result in the projector falling and causing injury.
  • Page 15 Important Information WARNING Do not place objects in front of the lens while the projector is operating. • Do not leave the lens cap on the lens while the projector is operating. The lens cap could get hot and be warped. •...
  • Page 16 Important Information CAUTION Power cord Handling the power cord • The projector should be installed close to an easily accessible power outlet. • When connecting the power cord to the projector’s AC IN terminal, make sure the connector is fully and firmly inserted. Be sure to fix the power cord using REQUIRED the power cord stopper.
  • Page 17 Important Information CAUTION Installation Securing the lens unit with the fall prevention wire • If the projector is going to be suspended from a ceiling or another high place, secure the lens unit using the fall prevention wire (sold separately). If the lens unit is not secured, it may fall down if it comes lose.
  • Page 18 Important Information CAUTION Handling batteries Incorrect usage of batteries can result in leaks or bursting. • Use the specified batteries only. • Insert batteries matching the (+) and (–) signs on each battery to the (+) and PROHIBITED (–) signs of the battery compartment. •...
  • Page 19 Important Information CAUTION Moving the projector • After the lens unit removed, have at least two people hold the handles to move the projector. Attempting to move the projector alone could result in back pain or other injuries. PROHIBITED • When moving the projector, do not hold anywhere but the handles. Otherwise the projector could fall and cause an injury.
  • Page 20 Important Information Laser Safety Caution WARNING CLASS 1 LASER PRODUCT [IEC 60825-1:2014] • The laser module is equipped in this product. Use of controls or adjustments of procedures other than those specified herein may result in hazardous radiation exposure. Laser energy exposure near aperture may cause burns. •...
  • Page 21 Important Information Risk groups This projector is classified as risk group 3 of IEC/EN 62471-5:2015. WARNING RG3 PRODUCT OF IEC/EN 62471-5:2015 • This projector is for professional use and must be installed in location where safety is assured. For this reason, be sure to consult your dealer as installation must be performed by a profes- sional installer.
  • Page 22 Important Information • Hazard zone The below figure describes the radiation zone (hazard zone) of light emitted by the projector that is classified as Risk Group 3 (RG3) of IEC/EN 62471-5:2015. Overhead view Side view a: Screen / b: Hazard zone Hazard zone (m) Lens Wide...
  • Page 23 Important Information • About the precautionary zone By providing a precautionary zone or physical barriers, it must prevent human eyes from entering the hazard zone. When the manager of the projector (operator) cannot prevent spectators from entering the hazard zone such as in public facilities, it is required to secure a space of 1 m or more from the hazard zone as “the precautionary zone”...
  • Page 24 Important Information ③ Example of downward projection installed on the ceiling a: Screen / b: Hazard zone / c: Precautionary zone / d: floor If the precautionary zone between the floor and the hazard zone can- CAUTION not be secured, it is necessary to prevent spectators from entering the area around the screen as shown in the figure on the right.
  • Page 25 Important Information CAUTION Please follow all safety precautions. Installing the projector • When planning the layout of the projector, make sure to follow the safety measures listed in the installation manual. • In order to avoid danger, either install the device within easy reach of a wall outlet or provide a device like a breaker to disconnect power to the projector in emergency.
  • Page 26 Important Information Notes on installation and maintenance Do not install or store in such places as those described below. • Locations that amplify vibrations and impacts If installed in places where the vibrations from power sources and the like are conveyed, or in vehicles or on vessels, etc.
  • Page 27 Important Information Cautions for ensuring the projector’s performance • If intense light like laser beams enters from the lens, it could lead to malfunction. • Consult your dealer before using in places where much cigarette smoke or dust is present. •...
  • Page 28 Important Information Clearance for Installing the Projector • When installing the projector, keep sufficient space around it, as described below. If not, the hot exhaust emitted from the projector may be taken back in. Also, make sure no wind from an air-conditioner hits the projector. The projector’s heat control system may detect an abnormality (temperature error) and automati- cally shut off the power.
  • Page 29 • Cinema Quality Picture logo, ProAssist, and Virtual Remote are trademarks or registered trademarks of Sharp NEC Display Solutions, Ltd. in Japan, in the United State and other countries. • The terms HDMI, HDMI High-Definition Multimedia Interface, HDMI Trade dress and the HDMI Logos are trademarks or registered trademarks of HDMI Licensing Administrator, Inc.
  • Page 30 1. Check the product overview, supplied items and part names 1-1. Introduction to the Projector This section introduces you to your new projector and describes the features and controls. • Liquid crystal type high brightness/high resolution projector This projector has a display resolution of 1920 dots × 1200 lines (WUXGA), an aspect ratio of 16:10 , and a brightness in 20000 lm*.
  • Page 31 A virtual remote control is displayed on the computer screen to perform simple controls such as turning the projector on/off, switching signals, etc. Please visit our web site for downloading each software. URL: https://www.sharp-nec-displays.com/dl/en/index.html • CRESTRON ROOMVIEW and Extron XTP compatibility The projector supports CRESTRON ROOMVIEW and Extron XTP, allowing multiple devices con- nected in the network to be managed and controlled from a computer.
  • Page 32 1. Check the product overview, supplied items and part names 1-2. What’s in the Box? Make sure your box contains everything listed. If any pieces are missing, contact your dealer. Please save the original box and packing materials if you ever need to ship your projector. Projector Dust cap for lens * The projector is shipped without a lens.
  • Page 33 1. Check the product overview, supplied items and part names 1-3. Part Names of the Projector Front The lens is sold separately. The description below is for when the XP-54ZL lens is mounted. 1. Exhaust vent 7. Remote Sensor Heated air is exhausted from here. This part receives signals from the remote control.
  • Page 34 1. Check the product overview, supplied items and part names Rear 1. Exhaust vent 6. Terminals Heated air is exhausted from here. Connect the cables for the various audio and video signals. 2. Intake vent 7. AC IN Terminal Takes in outside air to cool the unit. Connect the supplied power cord’s three- 3.
  • Page 35 1. Check the product overview, supplied items and part names Controls/Indicators 5. TEMP. Indicator (POWER) Button Indicates high temperatures around the Switches between projector’s power on and projector. standby. 6. INPUT Button When turning off the power (standby), pressing the button once will bring up a Selects the input signal.
  • Page 36 1. Check the product overview, supplied items and part names 9. ENTER Button Moves to the next menu when the on- screen menu is displayed. Confirms the item when the confirmation message is displayed. 10. EXIT Button Returns to the menu on the previous level when the on-screen menu is displayed.
  • Page 37 1. Check the product overview, supplied items and part names Terminal Panel Features 1. HDMI 1 IN Terminal (Type A) 6. AUDIO OUT Mini Jack (Stereo Mini) Connects to the output terminals of a com- Outputs the audio signal corresponding to puter, blu-ray player, etc.
  • Page 38 1. Check the product overview, supplied items and part names 10. REMOTE Terminal (Stereo Mini) Use this terminal for wired remote control of the projector. NOTE: • When a remote control cable is connected to the REMOTE terminal, infrared remote control operations cannot be performed.
  • Page 39 1. Check the product overview, supplied items and part names 1-4. Part Names of the Remote Control 1. Infrared Transmitter Remote control signals are sent via infrared signal. Point the remote control at the remote control receiver on the projector. 2.
  • Page 40 1. Check the product overview, supplied items and part names 9. ENTER Button Moves to the next menu when the on-screen menu is displayed. Confirms the item when the confirma- tion message is displayed. 10. FOCUS Button Opens the focus adjustment screen. Adjust the focus (of the lens) with the ◀...
  • Page 41 1. Check the product overview, supplied items and part names 17. Geometric. Button Displays [GEOMETRIC CORRECTION] from the on-screen menu. Use it to adjust distortions in projected images. 18. STATUS Button Displays [USAGE TIME] of [INFO.] from the on- screen menu. 19.
  • Page 42 1. Check the product overview, supplied items and part names 30. ID SET Button Used to set the control ID when performing indi- vidual operations on multiple projectors using the remote control. Also used to toggle the character keyboard when the character input screen is dis- played.
  • Page 43 1. Check the product overview, supplied items and part names Battery Installation 1. Press the catch and remove the battery cover. 2. Install AAA alkaline batteries. Ensure that you have the batteries’ polarity (+/−) aligned correctly. 3. Slip the cover back over the batteries until it snaps into place.
  • Page 44 1. Check the product overview, supplied items and part names Operating Range for Wireless Remote Control a: 7 m/276" / b: 20 m/787" / c: Remote sensor on projector cabinet / d: Remote control • The projector will not respond if there are objects between the remote control and the sensor, or if strong light falls on the sensor.
  • Page 45 1. Check the product overview, supplied items and part names Using the Remote Control in Wired Operation Connect one end of the remote cable to the REMOTE terminal and the other end to the remote jack on the remote control. REMOTE a: Remote jack NOTE:...
  • Page 46 2. Projecting an Image (Basic Operation) This section describes how to turn on the projector and to project a picture onto the screen. 2-1. Flow of Projecting an Image Step 1 • Connecting your computer / Connecting the power cord (→ page 18) Step 2 •...
  • Page 47 2. Projecting an Image (Basic Operation) 2-2. Connecting Your Computer/Connecting the Power Cord 1. Connect your computer to the projector. This section will show you a basic connection to a computer. Connect a commercially available HDMI cable between the computer's HDMI output connector and the projector's HDMI 1 IN or HDMI 2 IN connector.
  • Page 48 2. Projecting an Image (Basic Operation) HDMI 1 IN HDMI 2 IN Make sure that the prongs are fully inserted into both the AC IN and the wall outlet. To wall outlet a: Power cord (supplied) / b: HDMI cable (not supplied) •...
  • Page 49 2. Projecting an Image (Basic Operation) Using the power cord stopper To prevent the power cord from accidently removing from the AC IN of the projector, use the power cord stopper. NOTE: • If you pull on the power supply cord while the connector is fixed, the main unit may fall down and be damaged ①...
  • Page 50 2. Projecting an Image (Basic Operation) 2-3. Turning on the Projector WARNING The projector produces a strong light. When turning on the power, operate from the side or rear of the projector (outside the hazard zone). Also, when turning on the power, make sure no one within the projection range is looking at the lens.
  • Page 51 2. Projecting an Image (Basic Operation) Performing Lens Calibration After mounting the separately available lens unit or replacing a lens unit, perform [LENS CALIBRATION] by holding to press ZOOM/L-CALIB. button on the cabinet over two seconds. Calibration corrects the adjustable zoom, shift, and focus range.
  • Page 52 2. Projecting an Image (Basic Operation) Note on Startup screen When you first turn on the projector, you will get the Startup menu. This menu gives you the op- portunity to select one of the 30 menu languages. To select a menu language, follow these steps: 1.
  • Page 53 2. Projecting an Image (Basic Operation) 2-4. Selecting a Source Selecting the computer or video source NOTE: • Turn on the computer or video source equipment connected to the projector. Detecting the Signal Automatically Press the INPUT button for 1 second or longer. The projector will search for the available input source and display it.
  • Page 54 2. Projecting an Image (Basic Operation) Selecting Default Source You can set a source as the default source so that it will be displayed each time the projector is turned on. 1. Press the MENU button. The menu will be displayed. 2.
  • Page 55 2. Projecting an Image (Basic Operation) 2-5. Adjusting the Picture Size and Position Use the lens shift, the adjustable tilt foot, the zoom and the focus to adjust the picture size and position. Repeat these adjustments until you obtain the optimal projection conditions. In this chapter drawings and cables are omitted for clarity.
  • Page 56 2. Projecting an Image (Basic Operation) Adjusting the vertical position of a projected image (Lens shift) CAUTION • Perform the adjustment from behind or from the side of the projector. If adjustments are performed from the front, your eyes could be exposed to strong light and get injured. •...
  • Page 57 2. Projecting an Image (Basic Operation) NOTE: • If the lens is shifted to the maximum in the diagonal direction, the screen peripheral area will be dark or shaded. TIP: • The figure below shows the lens shift adjustment range (projection method: Desktop/Front) of the XP-54ZL lens unit. See page for other lens units.
  • Page 58 2. Projecting an Image (Basic Operation) Focus Recommend to perform the focus adjustment after leaving the projector under the state the TEST PATTERN has been projected for over 30 minutes. Applicable lens: XP-51ZL/XP-52ZL/XP-53ZL/NP51ZL/NP52ZL/NP53ZL 1. Press the FOCUS button. The [LENS FOCUS] control screen will be dis- played on.
  • Page 59 2. Projecting an Image (Basic Operation) 3. Press ▼ button to select the [PERIPHERY] on the on-screen menu, and then press either ◀ or ▶ button to align the focus of screen peripheral area. 4. Repeat steps 2 and 3 until the entire projec- tion screen is in focus.
  • Page 60 2. Projecting an Image (Basic Operation) Zoom 1. Press ZOOM/L-CALIB. button. The [ZOOM] adjustment screen will be displayed on. In another way, press the ZOOM button on the remote control. Press ◀▶ buttons to adjust zoom.
  • Page 61 2. Projecting an Image (Basic Operation) Adjusting the Tilt Foot 1. The position to project image may be ad- justed by the tilt foot positioned at four corners of the cabinet bottom. The tilt foot height can be adjusted by its turn. [To adjust the height of the projected image] The height of the projected image is adjusted by turning either front or rear tilt foot.
  • Page 62 2. Projecting an Image (Basic Operation) 2-6. Adjusting a picture and sound Adjusting the picture Display the on-screen menu and adjust the picture. (→ page 80) Turning Up or Down Volume Sound level from the AUDIO OUT terminal can be adjusted. Important: •...
  • Page 63 2. Projecting an Image (Basic Operation) 2-7. Turning off the Projector To turn off the projector: 1. First, press the (POWER) button on the projector cabinet or the STANDBY button on the remote control. The [POWER OFF / ARE YOU SURE ? / CARBON SAVINGS-SESSION 0.000[g-CO2]] message will appear.
  • Page 64 2. Projecting an Image (Basic Operation) 2-8. After Use 1. Unplug the power cord. ① Pull to an appropriate position while pushing down the knob of the power cord stopper. ② Press down the knob on the clamper to open the clamper and take out the power cord. a: Clamper / b: Knob (power cord stopper) / c: Knob (clamper) 2.
  • Page 65 3. Convenient Features 3-1. Turn off the light of the projector (SHUTTER) 1. Press the SHUTTER CLOSE ( ) button on the remote control. The light source will turn off temporarily. Press the SHUTTER OPEN ( ) button to allow the screen to become illuminated again.
  • Page 66 3. Convenient Features 3-3. Enlarging a Picture You can enlarge the picture up to four times. NOTE: • Depending on an input signal, the maximum magnification may be less than four times, or the function may be restricted. 1. Press and hold the CTL button and then press VOL./D-ZOOM (+) button on the remote control to magnify the picture.
  • Page 67 3. Convenient Features 3-4. Adjustment of luminance (brightness) Three [REF. LIGHT MODE] options can be selected according to the purpose of use. Brightness can be adjusted and controlled to maintain a constant brightness after adjustment. Function Description Page name REF. LIGHT MODE The adjustment values of the [REF.
  • Page 68 3. Convenient Features Display the [LIGHT MODE] screen 1. Press LIGHT button on the remote control. When [STANDARD] is selected for [MODE] The [REF. LIGHT MODE] screen will be displayed. When [PROFESSIONAL] is selected for [MODE] The [LIGHT MODE] screen will be displayed. Perform [LIGHT ADJUST] An explanation is given here using the [REF.
  • Page 69 3. Convenient Features Change [REF. LIGHT MODE] 1. With the cursor adjusted to [REF. LIGHT MODE], press the ENTER button. The [REF. LIGHT MODE] selection screen will be displayed. 2. Use the ▼▲ buttons to make a selection, and press the ENTER button. The display will return to the [REF.
  • Page 70 3. Convenient Features Checking Energy-Saving Effect [CARBON METER] This will display the energy-saving effect during the period of reduced projector light source as the amount of CO h emission reductions. This feature is called as [CARBON METER]. There are two messages: [TOTAL CARBON SAVINGS] and [CARBON SAVINGS-SESSION]. The [TOTAL CARBON SAVINGS] message shows the total amount of CO emission reduction from the time of shipment up to now.
  • Page 71 3. Convenient Features 3-5. Correcting Horizontal and Vertical Keystone Distortion [CORNERSTONE] Use the [CORNERSTONE] feature to correct keystone (trapezoidal) distortion to make the top or bot- tom and the left or right side of the screen longer or shorter so that the projected image is rectangular. 1.
  • Page 72 3. Convenient Features 5. Select [CORNERSTONE] and press the ENTER. Go back to display the [GEOMETRIC CORRECTION] screen of the on-screen menu. 6. Press the ▼ button to align with the [CORNERSTONE] and then press the ENTER button. The drawing shows the upper left icon ( ) is selected. The screen will switch to the [CORNERSTONE] screen.
  • Page 73 3. Convenient Features 11. Use the ▲▼◀▶ button to select another icon which points in the direction. On the [CORNERSTONE] screen, select [EXIT] or press the EXIT button on the remote control. The confirmation screen is displayed. 12. Press the ◀ or ▶ button to highlight the [OK] and press the ENTER button. This completes the [CORNERSTONE] correction.
  • Page 74 3. Convenient Features 3-6. Operation for the On-Screen Menu by a commercially available USB mouse Once a commercially available USB mouse is connected to this projector, it enables to perform the operation for the on-screen menu and the geometric correction easily. NOTE: •...
  • Page 75 3. Convenient Features Geometric correction The USB mouse can be used for [CORNERSTONE] CORRECTION, [HORIZONTAL CORNER], [VERTI- CAL CORNER], and [WARP]. In this clause, the [CORNERSTONE] CORRECTION by an USB mouse is explained as an example. 1. While the adjustment screen of the [COR- NERSTONE] CORRECTION is displayed, right click on the projection screen.
  • Page 76 3. Convenient Features 3-7. Preventing the Unauthorized Use of the Projector [START-UP LOCK] A keyword can be set for your projector using the Menu to avoid operation by an unauthorized user. When a keyword is set, turning on the projector will display the START-UP LOCK KEYWORD input screen.
  • Page 77 3. Convenient Features 6. Type in a combination of the four ▲▼◀▶ buttons and press the ENTER button. NOTE: • A keyword must be 4 to 10 digits in length. The [CONFIRM KEYWORD] screen will be displayed. NOTE: • Make a note of your keyword and store it in a safe place. 7.
  • Page 78 3. Convenient Features 3. Type in the correct keyword and press the ENTER button. The projector will display an image. NOTE: • The START-UP LOCK disable mode is maintained until the main power is turned off or unplugging the power cord. To disable the [START-UP LOCK] function: 1.
  • Page 79 3. Convenient Features 3-8. Controlling the Projector by Using an HTTP Browser Overview You can display the HTTP server screen of the projector by using a web browser and operating the projector with a computer or smartphone. Possible operations on the HTTP server screen •...
  • Page 80 3. Convenient Features 4. Start up the web browser and enter the address or URL in the input field. Specify the address or URL as “http://<IP Address of Projector>/index.html”. The HTTP server screen will be displayed. NOTE: • To use the projector in a network, consult with your network administrator about network settings. •...
  • Page 81 3. Convenient Features HTTP server screen The screen size of the terminal being used is automatically determined to display the computer screen or smartphone screen. You can also switch between the computer screen and the smartphone screen manually. • When switching the display from a computer to a smartphone Press the [SWITCH TO MOBILE] button at the top right of the screen.
  • Page 82 3. Convenient Features 3-9. Storing Changes for Lens Shift, Zoom, and Focus [LENS MEMORY] This function serves to store the adjusted values when using the [LENS SHIFT], [ZOOM], and [FO- CUS] functions of the projector. Adjusted values can be applied to the signal you selected. This will eliminate the need to adjust lens shift, focus, and zoom at the time of source selection.
  • Page 83 3. Convenient Features To store your adjusted values in [REF. LENS MEMORY]: 1. Press the MENU button. The menu will be displayed. 2. Press the ▶ button to select [SETUP] and press the ENTER button. 3. Press the ▶ button to select [INSTALLATION(2)].
  • Page 84 3. Convenient Features 4. Press the ▼ button to select [REF. LENS MEMORY] and press the ENTER button. The [REF. LENS MEMORY] screen will be displayed. 5. Make sure [PROFILE] is highlighted, then press the ENTER button. The [PROFILE] selection screen appears. 6.
  • Page 85 3. Convenient Features 8. Press the ◀ button to select and [YES] and press the ENTER button. Select a [PROFILE] number and save the adjusted [LENS SHIFT], [ZOOM], and [FOCUS] values to it. 9. Press the MENU button. The menu will be closed. TIP: •...
  • Page 86 3. Convenient Features To call up your adjusted values from [REF. LENS MEMORY]: 1. Press the MENU button. The menu will be displayed. 2. Press the ▶ button to select [SETUP] and press the ENTER button. 3. Press the ▶ button to select [INSTALLATION(2)]. 4.
  • Page 87 3. Convenient Features 5. Make sure [PROFILE] is highlighted, then press the ENTER button. The [PROFILE] selection screen appears. 6. Press the ▼/▲ buttons to select the [PROFILE] number, then press the ENTER button. Return to the [REF. LENS MEMORY] settings screen. 7.
  • Page 88 3. Convenient Features TIP: To call up the stored values from [LENS MEMORY]: 1. From the menu, select [ADJUST] → [LENS MEMORY] → [MOVE] and press the ENTER button. The confirmation screen will be displayed. 2. Press the ◀ button to select and [YES] and press the ENTER button. During projection, if the adjusted values for an input signal have been saved, the lens will shift.
  • Page 89 3. Convenient Features 3-10. Automatic correction of blurry images [ADAPTIVE FOCUS] Image brightness will vary with the type of video being projected and shutter aperture. These can affect the temperature inside the projecting lens and can result in a loss of optimal focus position. Use the ADAPTIVE FOCUS feature to automatically correct the focus and reduce this loss.
  • Page 90 4. Multi-Screen Projection This projector can be used singly or arranged in multiple units for multi-screen projection. 4-1. Things that can be done using multi-screen projection Case 1. Using a single projector to project two types of videos [PIP/PICTURE BY PICTURE] Connection example and projection image In the case of [PICTURE BY PICTURE]...
  • Page 91 4. Multi-Screen Projection 4-2. Using a single projector to project two types of videos at the same time [PIP/PICTURE BY PICTURE] The projector has a feature that allows you to view two different signals simultaneously. You have two modes: [PIP] mode and [PICTURE BY PICTURE] mode. The projection video in the first screen display is known as the main display while the projection video that is called out subsequently is known as the sub-display.
  • Page 92 4. Multi-Screen Projection Projecting two screens 1. Press the MENU button to display the on-screen menu and select [DISPLAY] → [PIP/PIC- TURE BY PICTURE]. This displays the [PIP/PICTURE BY PICTURE] screen in the on-screen menu. 2. Select [SUB INPUT] using the ▼/▲ buttons, and press the ENTER button. This displays the [SUB INPUT] screen.
  • Page 93 4. Multi-Screen Projection Switching the main display with the sub-display and vice versa 1. Press the MENU button to display the on-screen menu and select [DISPLAY] → [PIP/PIC- TURE BY PICTURE]. This displays the [PIP/PICTURE BY PICTURE] screen in the on-screen menu. 2.
  • Page 94 4. Multi-Screen Projection Restrictions • The following operations are enabled only for the main display. - Audio-visual adjustments - Video magnification / compression using the partial VOL./D-ZOOM (+)(−) buttons. However, magnification / compression is up to the positions set in [PICTURE BY PICTURE] → [BORDER] only.
  • Page 95 4. Multi-Screen Projection 4-3. Line up multiple projectors to display a high resolution image in a larger screen [TILING] This section provides procedures for projecting an image with a resolution of 3840 × 2160 (4K UHD) by using four projectors. Preparation: •...
  • Page 96 4. Multi-Screen Projection Setting [TILING] 1. Press the MENU button to display the on-screen menu and select [DISPLAY] → [PICTURE SETTING] → [MODE]. This displays the [MODE] screen. 2. Select [TILING] using the ▼/▲ buttons, and press the ENTER button. The display returns to the [PICTURE SETTING] screen.
  • Page 97 4. Multi-Screen Projection 4-4. Adjust boundaries of a projected image [EDGE BLENDING] This projector is equipped with an “[EDGE BLENDING] Function” that makes the edges (boundaries) of the projection screen indistinguishable. NOTE: • Before performing the Edge Blending function, place the projector in the correct position so that the image becomes square in the appropriate size, and then make optical adjustments (lens shift, focus, and zoom).
  • Page 98 4. Multi-Screen Projection Setting the overlap of projection screens ① Enable [EDGE BLENDING]. 1. Press the MENU button. The menu will be displayed. 2. Select [DISPLAY] → [EDGE BLENDING]. The [EDGE BLENDING] screen will be displayed. Align the cursor with [MODE] and then press the ENTER button.
  • Page 99 4. Multi-Screen Projection 4. Select an appropriate item from [TOP], [BOTTOM], [LEFT], and [RIGHT] for an area of overlapped edges, and turn on [CONTROL]. [TOP]: [OFF] [TOP]: [OFF] [LEFT]: [OFF] [RIGHT]: [ON] [LEFT]: [ON] [RIGHT]: [OFF] [BOTTOM]: [ON] [BOTTOM]: [ON] [TOP]: [ON] [TOP]: [ON] [LEFT]: [OFF]...
  • Page 100 4. Multi-Screen Projection ② Adjust [POSITION] and [RANGE] to determine an area of overlapped edges of images projected from each projector. When [MARKER] is set to [ON], markers of four colors are displayed on the screen. The cyan and green markers represent the edges of the region where images overlap, the magenta and red markers represent the range of overlapping (region/width).
  • Page 101 4. Multi-Screen Projection Fit the edge of the overlapping area to the edge of the image with [POSITION], then adjust the overlapping area (width) with [RANGE]. In the case of the figure on the previous page, first set the cyan marker to the edge of the image on the left screen and the green marker to the edge of the image on the right screen.
  • Page 102 4. Multi-Screen Projection 2. Select one option among nine by ▲ or ▼. Black Level Adjustment This adjusts the black level of the overlapping area and the non-overlapping area of the multi-screen (EDGE BLENDING). Adjust the brightness level if you feel the difference is too large. NOTE: •...
  • Page 103 4. Multi-Screen Projection 2. Use the ◀, ▶, ▼ or ▲ button to select an item and use the ◀ or ▶ to adjust the black level. Do this for the other projector if necessary. Once adjustments of all the projectors are completed, make the [SYNCHRONOUS CONTROL] settings to all four projectors, for example, turn the power of on and off simultaneously with a single remote control.
  • Page 104 4. Multi-Screen Projection Making the [SYNCHRONOUS CONTROL] setting This setting is used to operate all the projectors with a single remote control. (→ page 132) Synchronized functions: POWER ON/OFF, AV MUTE, SHUTTER OPEN/CLOSE, SIGNAL MUTE, DYNAMIC CONTRAST, AUTO BLACK SHUTTER When the HDBaseT IN port and HDBaseT OUT port are connected in a daisy chain (→...
  • Page 105 4. Multi-Screen Projection Adjust using a computer or smartphone [EDGE BLENDING] can be easily done using a computer or smartphone connected to the projectors via a network. Connect to the HTTP server (→ page 50) and display the [EDGE BLENDING] tab. Screen for computer Screen for smartphone The [EDGE BLENDING] setting/adjustment items are displayed on one screen and can be operated...
  • Page 106 5. Using On-Screen Menu 5-1. Using the Menus NOTE: • The on-screen menu may not be displayed correctly while interlaced motion video image is projected. 1. Press the MENU button on the remote control or the projector cabinet to display the menu. NOTE: •...
  • Page 107 5. Using On-Screen Menu 5-2. Menu Elements Slide bar Solid triangle Operation Guide Source Highlight Radio button Menu mode Administrator Symbol REF. LIGHT MODE symbol Off Timer remaining time Thermometer symbol Key Lock symbol Menu windows or dialog boxes typically have the following elements: Highlight Indicates the selected menu or item.
  • Page 108 5. Using On-Screen Menu Using the character input screen Highlight the item for text input and press the ENTER button to bring up the character input screen. a: Text box / b: Highlight / c: Operation Guide 1. Press the ▼▲◀▶ buttons to highlight a character and then press the ENTER button. The character will be entered.
  • Page 109 5. Using On-Screen Menu 5-3. List of Menu Items • Some menu items are not available depending on the input source. • [BASIC] menu items are indicated by shaded area. Menu Item Default Options INPUT HDMI1 HDMI2 HDBaseT ENTRY LIST TEST PATTERN ADJUST PICTURE...
  • Page 110 5. Using On-Screen Menu Menu Item Default Options ADJUST IMAGE OPTIONS HORIZONTAL VERTICAL BLANKING TOP, BOTTOM, LEFT, RIGHT OVERSCAN AUTO, 0[%], 5[%], 10[%] ASPECT RATIO AUTO (HDTV/SDTV) AUTO, NORMAL, 4:3, LETTERBOX, WIDE SCREEN, ZOOM, FULL AUTO (COMPUTER) AUTO, NORMAL, 4:3, 5:4, 16:9, 15:9, 16:10, FULL, NATIVE VIDEO NOISE REDUCTION...
  • Page 111 5. Using On-Screen Menu Menu Item Default Options DISPLAY EDGE BLENDING MODE OFF, ON MARKER OFF, ON CONTROL OFF, ON RANGE POSITION BOTTOM CONTROL OFF, ON RANGE POSITION LEFT CONTROL OFF, ON RANGE POSITION RIGHT CONTROL OFF, ON RANGE POSITION BLEND CURVE OFF, 1, 2, 3, 4, 5, 6, 7, 8, 9 BLACK LEVEL...
  • Page 112 5. Using On-Screen Menu Menu Item Default Options SETUP MENU(2) MENU ANGLE 0° 0°, 90°, 270° MENU POSITION CENTER TOP-LEFT, TOP-CENTER, TOP-RIGHT, CENTER-LEFT, CENTER, CENTER-RIGHT, BOTTOM-LEFT, BOTTOM-CENTER, BOTTOM-RIGHT INSTALLATION(1) ORIENTATION AUTO AUTO, DESKTOP FRONT, CEILING REAR, DESKTOP REAR, CEILING FRONT SCREEN SCREEN TYPE FREE...
  • Page 113 5. Using On-Screen Menu Menu Item Default Options SETUP CONTROL(1) TOOLS ADMINISTRATOR MENU MODE ADVANCED ADVANCED, BASIC MODE NOT SAVE SETTING VALUES OFF, ON PROGRAM ENABLE OFF, ON TIMER SETTINGS EDIT ACTIVE TIME FUNCTION ADVANCED SETTINGS REPEAT DATE AND TIME TIME ZONE SETTINGS SETTINGS DATE AND TIME SETTINGS...
  • Page 114 5. Using On-Screen Menu Menu Item Default Options SETUP NETWORK WIRED LAN INTERFACE LAN, HDBaseT SETTINGS PROFILES DISABLE, PROFILE 1, PROFILE 2 DHCP OFF, ON IP ADDRESS SUBNET MASK GATEWAY AUTO DNS OFF, ON DNS CONFIGURATION RECONNECT PROJECTOR NAME PROJECTOR NAME PJ-******** DOMAIN HOST NAME...
  • Page 115 5. Using On-Screen Menu Menu Item Default Options SETUP POWER OPTIONS POWER-SAVING OFF, ON DIRECT POWER ON OFF, ON AUTO POWER ON SELECT OFF, HDMI1, HDMI2, HDBaseT, SDI AUTO POWER OFF 0:15 OFF, 0:05, 0:10, 0:15, 0:20, 0:30, 1:00 OFF TIMER OFF, 0:30, 1:00, 2:00, 4:00, 8:00, 12:00, 16:00 RESET CURRENT SIGNAL...
  • Page 116 5. Using On-Screen Menu Menu Item Default Options INFO. CONDITIONS INTAKE TEMPERATURE EXHAUST TEMPERATURE ATMOSPHERIC PRESSURE INSTALLATION POSITION X-AXIS Y-AXIS Z-AXIS HDBaseT SIGNAL QUALITY OPERATION MODE LINK STATUS HDMI STATUS Art-Net(1) Art-Net(2) Ch10 Ch11 Ch12 SYNCHRO MAIN SUB1 SUB2 SUB3...
  • Page 117 5. Using On-Screen Menu 5-4. Menu Descriptions & Functions [INPUT] HDMI1 This projects the video of the device connected to the HDMI 1 IN terminal. HDMI2 This projects the video of the device connected to the HDMI 2 IN terminal. HDBaseT Projects the video of the device connected to the HDBaseT IN port.
  • Page 118 5. Using On-Screen Menu Using the Entry List When any source adjustments are made, the adjustments are automatically registered in the Entry List. The (adjustment values of ) registered signals can be loaded from the Entry List whenever necessary. However, only up to 100 patterns can be registered in the Entry List. When 100 patterns have been registered in the Entry List, an error message is then displayed and no additional patterns can be registered.
  • Page 119 5. Using On-Screen Menu Calling up a signal from the Entry List [ (LOAD)] 1. Press the ▲ or ▼ button to select a signal and press the ENTER button. Editing a signal from the Entry List [ (EDIT)] 1. Press the ▲ or ▼ button to select a signal you wish to edit. 2.
  • Page 120 5. Using On-Screen Menu Cutting a signal from the Entry List [ (CUT)] 1. Press the ▲ or ▼ button to select a signal you wish to delete. 2. Press the ◀, ▶, ▲, or ▼ button to select [ (CUT)] and press the ENTER button.
  • Page 121 5. Using On-Screen Menu 5-5. Menu Descriptions & Functions [ADJUST] [PICTURE] [MODE] This function allows you to determine how to save settings for [DETAIL SETTINGS] of [PRESET] for each input. STANDARD Saves settings for each item of [PRESET] (Preset 1 through 7) PROFESSIONAL Saves all the settings of [PICTURE] for each input.
  • Page 122 5. Using On-Screen Menu [DETAIL SETTINGS] [GENERAL] Storing Your Customized Settings [REFERENCE] This function allows you to store your customized settings in [PRESET 1] to [PRESET 7]. First, select a base preset mode from [REFERENCE], then set [GAMMA SETTING] and [COLOR TEM- PERATURE].
  • Page 123 5. Using On-Screen Menu Adjusting Brightness and Contrast [DYNAMIC CONTRAST] Light output is automatically adjusted to match the image and provide optimal image contrast. Dynamic contrast is disabled. NORMAL Normal settings. ENHANCED Sets the light source output adjustment to high. This creates a sharper image than NORMAL. NOTE: •...
  • Page 124 5. Using On-Screen Menu Adjusting White Balance [WHITE BALANCE] This allows you to adjust the white balance. Contrast for each color (RGB) to adjust the white level of the screen; Brightness for each color (RGB) is used to adjust the black level of the screen. [COLOR CORRECTION] Corrects the color for all signals.
  • Page 125 5. Using On-Screen Menu [CONTRAST] Adjusts the intensity of the image according to the incoming signal. [BRIGHTNESS] Adjusts the brightness level or the back raster intensity. [SHARPNESS] Controls the detail of the image. [COLOR] Increases or decreases the color saturation level. [HUE] Varies the color level from +/−...
  • Page 126 5. Using On-Screen Menu [IMAGE OPTIONS] Adjusting Horizontal/Vertical Position [HORIZONTAL/VERTICAL] Adjusts the image location horizontally and vertically. NOTE: • The adjustments for [HORIZONTAL] and [VERTICAL] will be stored in memory for the current signal. The next time you project the signal with the same resolution, horizontal and vertical frequency, its adjustments will be called up and applied.
  • Page 127 5. Using On-Screen Menu Selecting Overscan Percentage [OVERSCAN] Select overscan percentage (Auto, 0%, 5% and 10%) for signal. Projected image Overscaned by 10% NOTE: • The [OVERSCAN] item is not available: - when [NATIVE] is selected for [ASPECT RATIO]. Selecting the Aspect Ratio [ASPECT RATIO] Use this function to select the screen’s lateral:longitudinal aspect ratio.
  • Page 128 5. Using On-Screen Menu Options Function NATIVE The projector displays the current image in its true resolution when the incoming signal has a lower or higher resolution than the projector’s native resolution. (→ page 171) When the incoming signal has a higher resolution than the projector’s native resolution, the center of an image will be displayed.
  • Page 129 5. Using On-Screen Menu [VIDEO] Using Noise Reduction [NOISE REDUCTION] When projecting a video image, you can use the [NOISE REDUCTION] function to reduce the screen noise (roughness and distortion). Depending on the noise level, the noise reduction effect can be set to [OFF], [LOW], [MEDIUM] or [HIGH].
  • Page 130 5. Using On-Screen Menu [HDR MODE] AUTO Automatically distinguishes HDR signal. Projects the image based on the input signal Projects the image conforming to the HDR signal NOTE: • These options are available exclusively for 4K signal. Using the Lens Memory Function [LENS MEMORY] This function serves to store the adjusted values for each input signal when using the [LENS SHIFT], [ZOOM], and [FOCUS] functions of the projector.
  • Page 131 5. Using On-Screen Menu To store your adjusted values in [LENS MEMORY]: 1. Project the connected device signal you want to adjust. 2. Adjust the projecting image of position, size and focus by the SHIFT/HOME POSITION, ZOOM +/−, and FOCUS +/− buttons. •...
  • Page 132 5. Using On-Screen Menu To automatically apply the adjusted values at the time of source selection: 1. From the menu, select [LOAD BY SIGNAL] and press the ENTER button. 2. Press the ▼ button to select [ON] and press the ENTER button. This will move the lens automatically to the position at the time of source selection according to the adjusted values.
  • Page 133 5. Using On-Screen Menu 5-6. Menu Descriptions & Functions [DISPLAY] [PIP/PICTURE BY PICTURE] SUB INPUT Select the input signal to be displayed in the sub-display. Please refer to “Using a single projector to project two types of videos at the same time [PIP/PICTURE BY PICTURE]”...
  • Page 134 5. Using On-Screen Menu BORDER Select the display boundary of the main display and sub-display of the [PICTURE BY PICTURE] screen. Sub-display Main display Sub-display Main display Main display Sub-display Display boundary TIP: • Seven options from zero to six are available. [GEOMETRIC CORRECTION] MODE Set pattern for correcting distortion.
  • Page 135 5. Using On-Screen Menu THROW RATIO Adjusts according to the projection ratio of the optional lens used. Lens unit Adjustment range XP-51ZL/NP51ZL 5 - 7 XP-52ZL/NP52ZL 6 - 9 XP-53ZL/NP53ZL 8 - 13 XP-54ZL/NP54ZL 12 - 21 XP-55ZL/NP55ZL 19 - 40 XP-56ZL/NP56ZL 39 - 75 NOTE:...
  • Page 136 5. Using On-Screen Menu CORNERSTONE Display the 4-point correction screen and adjust the trapezoidal distortion of the projection screen. Please refer to “Correcting Horizontal and Vertical Keystone Distortion [CORNERSTONE]” (→ page 42) for details on the operation. HORIZONTAL CORNER/VERTICAL CORNER Distortion correction for corner projection such as wall surfaces.
  • Page 137 5. Using On-Screen Menu Adjustment method 1. Align the cursor with the [HORIZONTAL CORNER] or [VERTICAL CORNER] of the [GEOMETRIC CORRECTION] menu and then press the ENTER button. • The adjustment screen will be displayed. 2. Press the ▼▲◀▶ buttons to align the cursor (yellow box) with the target adjustment point and then press the ENTER button.
  • Page 138 5. Using On-Screen Menu [Adjustment points of the [VERTICAL CORNER] screen and movement points of the projec- tion screen] Point d will be displaced in a parallel manner at the same time as Points a, d, f Point e will be displaced in a parallel manner at the same time as Points f, g, h 4.
  • Page 139 5. Using On-Screen Menu Adjustment method 1. Align the cursor with the [WARP] of the [GEOMETRIC CORRECTION] menu and the press the ENTER. • Adjustment screen will be displayed on. 2. Press the ▼▲◀▶ buttons to align the cursor (blue box) with the target adjustment point and then press the ENTER.
  • Page 140 5. Using On-Screen Menu PC TOOL Recall the geometric correction data that is registered in the projector beforehand. Three types of correction data can be registered. In addition, recall the geometric correction data that is registered in the projector after adjusting with the ProAssist software application.
  • Page 141 5. Using On-Screen Menu [EDGE BLENDING] This adjusts the edges (boundaries) of the projection screen when projecting high resolution videos using a combination of several projectors in the up, down, left and right positions. MODE This enables or disables the [EDGE BLENDING] function. When [MODE] is set to [ON], the [MARKER], [TOP], [BOTTOM], [LEFT], [RIGHT], [BLACK LEVEL], and [BLEND CURVE] settings can be adjusted.
  • Page 142 5. Using On-Screen Menu [PICTURE SETTING] This sets the division conditions for reducing or enlarging the image area and displaying it in the desired position or for projecting using a combination of several projectors. Please refer to “Multi-Screen Projection” (→ page 61) for details. MODE Use the projector in a standalone state.
  • Page 143 5. Using On-Screen Menu Conditions for using tiling • All the projectors need to fulfil the following conditions. - The panel size must be the same - The projection screen size must be the same - The left and right ends or top and bottom ends of the projection screen must be consistent. - The settings for the [LEFT] and [RIGHT] of the [EDGE BLENDING] are the same - The settings for the [TOP] and [BOTTOM] of the [EDGE BLENDING] are the same If the tiling conditions are satisfied, the video screen of the projector at each installation position...
  • Page 144 5. Using On-Screen Menu 5-7. Menu Descriptions & Functions [SETUP] [MENU(1)] Selecting Menu Language [LANGUAGE] You can choose one of 30 languages for on-screen instructions. Selecting Menu Color [COLOR SELECT] You can choose between two options for menu color: [COLOR] and [MONOCHROME]. Selecting Menu Brightness [OSD BRIGHTNESS] Select the brightness of the On-Screen display (menu, source display and messages) from 10 levels.
  • Page 145 5. Using On-Screen Menu [MENU(2)] [MENU ANGLE] Select the direction for displaying the menu. [MENU POSITION] Shift the menu displaying position. You can choose from 9 locations. TIP: • The display position of the menu is saved even when the power supply of the projector is turned off. •...
  • Page 146 5. Using On-Screen Menu DESKTOP REAR CEILING FRONT TIP: • Check whether the automatic [DESKTOP FRONT] is installed within ± 10 degrees for floor installation and whether the [CEILING FRONT] is within ±10 degrees for ceiling installation. Select manually when the projection screen is inverted. Selecting Aspect Ratio and Position for Screen [SCREEN] [SCREEN TYPE] Sets the aspect ratio of the projection screen.
  • Page 147 5. Using On-Screen Menu Using the Wall Color Correction [WALL COLOR] This function allows for quick adaptive color correction in applications where the screen material is not white. NOTE: • Selecting [WHITEBOARD] reduces light source brightness. [REF. LIGHT MODE] Three [REF. LIGHT MODE] options can be selected according to the purpose of use. You can also adjust output power and change luminance (brightness).
  • Page 148 5. Using On-Screen Menu TIP: • Brightness normally decreases with use, but by selecting [CONSTANT BRIGHTNESS] mode, sensors inside the projector detect brightness and automatically adjust the output, thereby maintaining a constant brightness throughout the life of the light module. However, if output is already at its maximum, brightness will decrease with use.
  • Page 149 5. Using On-Screen Menu [INSTALLATION(2)] [SHUTTER SETTINGS] Enabling and disabling the lens shutter function. POWER ON SHUTTER OPEN When the power is turned on, the light source comes on and the picture is projected. CLOSE The light source does not come on when the power is turned on. When the SHUTTER button is pressed, the shutter is released and the light source is turned on.
  • Page 150 5. Using On-Screen Menu [LENS POSITION] Set back the lens to the home position. [LENS CALIBRATION] The adjustment range of the zoom, focus, and shift of the mounted lens is calibrated. Be sure to carry out [LENS CALIBRATION] after replacing the lens. [ADAPTIVE FOCUS] Reduces focus misalignment occurring from temperature changes in the projecting lens.
  • Page 151 5. Using On-Screen Menu [CONTROL(1)] [TOOLS] ADMINISTRATOR MODE This allows you to select [MENU MODE], save settings, and set a password for the administrator mode. MENU MODE Select either [BASIC] or [ADVANCED] menu. — (→ page 80) NOT SAVE SETTING VALUES Placing a check mark will not save your projector settings.
  • Page 152 5. Using On-Screen Menu 2. Select a blank program number and press the ENTER button. The [ (EDIT)] screen will be displayed. 3. Make settings for each item as required. ACTIVE Place a check mark to enable the program. Select days of the week for the program timer. To execute the program from Monday to Friday, select [MON-FRI].
  • Page 153 5. Using On-Screen Menu 5. Select [ (BACK)] and press the ENTER button. You will be returned to the [PROGRAM TIMER] screen. 6. Select [EXIT] and press the ENTER button. You will be returned to the [TOOLS] screen. NOTE: • Up to 30 different timer settings can be programmed. •...
  • Page 154 5. Using On-Screen Menu Editing the programmed settings 1. On the [PROGRAM LIST] screen, select a program you want to edit and press the ENTER button. 2. Change the settings on the [EDIT] screen. 3. Select [OK] and press the ENTER button. The programmed settings will be changed.
  • Page 155 5. Using On-Screen Menu DATE AND TIME SETTINGS You can set the current time, month, date, and year. NOTE: • The projector has a built-in clock. The clock will keep working for about a month after the main power is turned off. If the main power is off for a month or more, the built-in clock will cease.
  • Page 156 5. Using On-Screen Menu Selecting Communication Speed [COMMUNICATION SPEED] This feature sets the communication speed for the PC Control port (D-Sub 9P). Make sure to set the appropriate speed for the device to connect. [PC CONTROL(HDBaseT)] Set this to [ON] when controlling the projector from a computer using RS-232C via an HDBaseT- compatible transmitter (sold separately).
  • Page 157 5. Using On-Screen Menu Assigning or Changing the Control ID 1. Turn on the projector. 2. Press the ID SET button on the remote control. The [CONTROL ID] screen will be displayed. If the projector can be operated with the current remote control ID, the [ACTIVE] will be displayed.
  • Page 158 5. Using On-Screen Menu Turning On or Off Remote Sensor [REMOTE SENSOR] This option determines which remote sensor on the projector is enabled in wireless mode. The options are: [FRONT/BACK], [FRONT], [BACK], and [HDBaseT]. NOTE: • The remote control of the projector will not be able to receive signals if the power supply of the HDBaseT transmission device connected to the projector is switched on when this has been set to [HDBaseT].
  • Page 159 5. Using On-Screen Menu [CONTROL(2)] [ADMIN PASSWORD] Set the password for the projector administrator. If you set the administrator's password, the confirmation screen will be displayed when you set the following items. You must enter the password. On-screen menu: [ADMINISTRATOR MODE], [START-UP LOCK], [ADMIN PASSWORD], [USER ACCOUNT], [NETWORK SETTINGS], and [INITIALIZE PROJECTOR] HTTP server: [NETWORK] tab and [LOGO] tab...
  • Page 160 5. Using On-Screen Menu [USER ACCOUNT] Up to three user accounts for use with [HTTP SERVER] authentication and [AUTH. PC CONTROL] can be registered. EDIT Set the user name and password. Perform the setting using 5 to 16 characters (letters or numbers). NOTE: •...
  • Page 161 5. Using On-Screen Menu [SYNCHRONOUS CONTROL] When projecting from multiple projectors (multi-screen projection, stack projection, etc.), all the projectors can be operated simultaneously with a single remote control (→ page 75). The projector set as the main projector controls the sub-projectors connected by HDBaseT daisy chain (→ page 158) or wired LAN (→...
  • Page 162 5. Using On-Screen Menu [NETWORK SETTINGS] Configure the various settings when using the projector connected to a network. Important: • Consult with your network administrator about these settings. • When using a wired LAN, connect the LAN cable to the LAN port on the projector. (→ page 157) •...
  • Page 163 5. Using On-Screen Menu [WIRED LAN] INTERFACE Select [LAN] for using the LAN port for connecting to the wired LAN. — Select [HDBaseT] for using the HDBaseT IN port for connecting to the wired LAN. PROFILES • The settings for the wired LAN can be recorded in the projector —...
  • Page 164 5. Using On-Screen Menu [ALERT MAIL] ALERT MAIL This option will notify your computer of error messages via e-mail when — using wireless or wired LAN. Placing a checkmark will turn on the Alert Mail feature. Clearing a checkmark will turn off the Alert Mail feature. Sample of a message to be sent from the projector: Subject: [Projector] Projector Information THE COOLING FAN HAS STOPPED.
  • Page 165 5. Using On-Screen Menu Up to 32 alphanumeric PJLink Configure the settings for using PJLink. characters Set the password. PASSWORD, CONFIRM PASSWORD CLASS Switches between Class 1 and Class 2. DESTINATION When the [CLASS] is set to [CLASS2], input the IP address of the destination.
  • Page 166 For the specifications related to the required authentication procedure using the application software, please see the “Control Command Authentication Flow Specifications” for your projector, uploaded on our web site. https://www.sharp-nec-displays.com/dl/en/pj_manual/lineup.html Art-Net Art-Net is a communication protocol for transmitting and receiving DMX512 —...
  • Page 167 5. Using On-Screen Menu [SOURCE OPTIONS] Selecting Default Source [DEFAULT INPUT SELECT] You can set the projector to default to any one of its inputs each time the projector is turned on. LAST Sets the projector to default to the previous or last active input each time the projector is turned on. Searches for an active source in order of HDMI1 →...
  • Page 168 5. Using On-Screen Menu [EDID VERSION] Switch the EDID version for the HDMI 1 IN and HDMI 2 IN terminals. MODE1 Supports general signal MODE2 Supports 4K signal Select this mode for displaying 4K image using the device supporting 4K NOTE: •...
  • Page 169 5. Using On-Screen Menu [POWER OPTIONS] [POWER-SAVING] Select the standby mode: This setting is to keep the standby power consumption to the minimum necessary. The standby state changes automatically depending on the projector settings and the state and duration of connected devices (→ page 180). The consumption power also changes according to the standby state.
  • Page 170 5. Using On-Screen Menu Turning On the Projector by Detecting Input Signal [AUTO POWER ON SELECT] Under the state of standby or sleep, the projector automatically detects and projects synchroniz- ing signal input from the selected terminals among [HDMI1], [HDMI2], [HDBaseT] and [SDI] by this function.
  • Page 171 5. Using On-Screen Menu Returning to Factory Default [RESET] The [RESET] feature allows you to change adjustments and settings to the factory preset for a (all) source (s) except the following: [CURRENT SIGNAL] Resets the adjustments for the current signal to the factory preset levels. The items that can be reset are: [PRESET], [CONTRAST], [BRIGHTNESS], [COLOR], [HUE], [SHARPNESS], [ASPECT RATIO], [HORIZONTAL], [VERTICAL], [CLOCK], [PHASE], and [OVERSCAN].
  • Page 172 5. Using On-Screen Menu 5-8. Menu Descriptions & Functions [INFO.] [USAGE TIME] LIGHT HOURS USED (H) PROJECTOR HOURS USED (H) TOTAL CARBON SAVINGS [kg-CO2] • The value of [LIGHT HOURS USED] reflects the temperature of the operating environment and the [LIGHT MODE] setting in the actual operating time. •...
  • Page 173 5. Using On-Screen Menu [VERSION] SOFTWARE [OTHERS] DATE TIME PROJECTOR NAME MODEL NO. SERIAL NUMBER CONTROL ID* LENS ID • Even if an NP model lens unit is installed, the XP model will be displayed in [LENS ID]. * [CONTROL ID] will be displayed when [CONTROL ID] has been set up. [CONDITIONS] INTAKE TEMPERATURE EXHAUST TEMPERATURE...
  • Page 174 5. Using On-Screen Menu [HDBaseT] SIGNAL QUALITY OPERATION MODE LINK STATUS HDMI STATUS The [HDBaseT] page displays the HDBaseT IN port’s connection status. SIGNAL QUALITY Indicates the signal’s quality level. NORMAL: The signal quality level is normal. WARNING: The quality level is one at which noise may be generated in the picture. ABNORMAL: The quality level is abnormal, so the picture will be disturbed or may not display.
  • Page 175 6. Attachment/detachment of parts sold separately 6-1. Lens unit (sold separately) Six separate bayonet style lenses can be used with this projector. The descriptions here are for the XP-54ZL lens. Mount other lenses in the same manner. After installing or replacing the lens unit, press the ZOOM/L-CALIB. button on the projector to carry out [LENS CALIBRATION].
  • Page 176 6. Attachment/detachment of parts sold separately 2. Remove the lens cap on the back of the lens. NOTE: • Make sure to remove the lens cap at the unit back side. If the lens unit with the lens cap remaining on is installed on the projector, it may cause of malfunction.
  • Page 177 6. Attachment/detachment of parts sold separately 5. With the plate on the lens unit facing up, insert the lens unit into the projector's lens hole. Align the position of the connector and gently insert it as far back as possible. NOTE: •...
  • Page 178 6. Attachment/detachment of parts sold separately Removing Preparations: 1. Turn on the projector and display an image. 2. Press and hold the SHIFT/HOME POSITION button over 2 seconds. The lens position will be moved to the home position. 3. Turn off the main power switch, and then unplug the power cord. 4.
  • Page 179 6. Attachment/detachment of parts sold separately 3. Gently pull the lens unit out from the pro- jector. Once the lens unit has been removed, attach the rear lens cap included with the lens unit before storing. 4. Attach the lens cover to the projector. (1) Leave a gap of about 2 cm when attaching the lens cover.
  • Page 180 6. Attachment/detachment of parts sold separately 6-2. Eye bolts (sold commercially) Eye bolts can be used to lift and move the projector or to install it suspended from the ceiling. WARNING • Please ask your dealer to attach the eye bolts or for installation or transportation using the eye bolts.
  • Page 181 7. Connecting to Other Equipment CAUTION • Be sure to turn off the projector before connecting the projector to an external device. If projected light enters your eyes, it may cause visual impairment. NOTE: • The connection cable is not enclosed with the projector. Please get ready a suitable cable for the connection. For HDMI, LAN, BNC, RS-232C, and AUDIO, please use a shielded signal cable.
  • Page 182 7. Connecting to Other Equipment 7-1. Connecting Your Computer • Connect a commercially available HDMI cable between the computer’s HDMI output connector and the projector’s HDMI 1 IN or HDMI 2 IN connector. HDMI 1 IN HDMI 2 IN AUDIO OUT a: HDMI cable (not supplied) / b: Audio cable (not supplied) •...
  • Page 183 7. Connecting to Other Equipment 7-2. Connecting audio video equipment You can connect the HDMI output of your Blu-ray player, hard disk player, or notebook type PC to the HDMI 1 IN or HDMI 2 IN connector of your projector. The SDI input terminal can also be used to connect to professional video devices, etc.
  • Page 184 7. Connecting to Other Equipment NOTE: • Use cables that are 5C-FB or higher (5C-FB, 7C-FB, etc.) or Belden 1694A or higher. In addition, use cables with a cable length 100m or less. • The length of cables that can be used may differ, depending on the signal. TIP: •...
  • Page 185 7. Connecting to Other Equipment 7-3. Connecting to a HDBaseT transmission device (sold commercially) Use a LAN cable sold commercially to connect the HDBaseT IN port of the projector to a HDBaseT transmission device sold commercially. The HDBaseT IN port of the projector supports HDMI signals (HDCP) from transmission devices, control signals from external devices (serial, LAN) and remote control signals (IR commands).
  • Page 186 7. Connecting to Other Equipment 7-4. Connecting to a Wired LAN The projector comes standard with a LAN port which provides a LAN connection using a LAN cable. To use a LAN connection, you are required to set the LAN on the projector menu. Select [SETUP] → [NETWORK SETTINGS] →...
  • Page 187 7. Connecting to Other Equipment 7-5. Connecting several projectors Example of a daisy change connection It enables to project HDMI, HDBaseT image on several projectors connecting the HDBaseT IN port and the HDBaseT OUT port by LAN cable. You can connect up to four devices of the same model. HDBaseT OUT HDBaseT IN a: Master projector / b: Other projector...
  • Page 188 7. Connecting to Other Equipment Example of a wired LAN connection Connect this unit’s LAN port to the router using a LAN cable. For details about the LAN settings, see [WIRED LAN] (→ page 134). The video signal is input to the different projectors using a distributor. HDMI1IN a: HDMI distributor / b: Router NOTE:...
  • Page 189 8. Maintenance 8-1. Cleaning the Lens WARNING • Turn off the power, unplug the power plug from the socket and remove the lens for cleaning. If the unit turns on while cleaning the lens, the strong light from the lens could damage your eyes.
  • Page 190 8. Maintenance 8-2. Cleaning the Cabinet WARNING • Turn off the projector, and unplug the projector before cleaning. • Please do not use a spray containing flammable gas to remove dust attached to the cabinet. Doing so may result in fires. •...
  • Page 191 9. Appendix 9-1. Throw distance and screen size Six separate bayonet style lenses can be used on this projector. Refer to the information on this page and use a lens suited for the installation environment (screen size and throw distance). Projection range for the different lenses (Recommended distance from projector to screen) XP-51ZL/NP51ZL...
  • Page 192 9. Appendix Lens types and throw distance (Aspect ratio 16:10) (Unit: inch) Lens model name and throw distance Screen size XP-51ZL/ XP-52ZL/ XP-53ZL/ XP-54ZL/ XP-55ZL/ XP-56ZL/ Width × Height (inches) NP51ZL NP52ZL NP53ZL NP54ZL NP55ZL NP56ZL 51 × 32 26 – 32 32 –...
  • Page 193 9. Appendix Lens types and throw distance (Aspect ratio 16:9) (Unit: inch) Lens model name and throw distance Screen size XP-51ZL/ XP-52ZL/ XP-53ZL/ XP-54ZL/ XP-55ZL/ XP-56ZL/ Width × Height (inches) NP51ZL NP52ZL NP53ZL NP54ZL NP55ZL NP56ZL 52 × 29 27 - 33 33 - 45 44 - 65 64 - 104 101 - 204 212 - 398...
  • Page 194 9. Appendix Calculation of the throw distance from the screen size L: Throw distance W: Screen width Lens model name Calculation formula (Zoom min to max) XP-51ZL/NP51ZL L = W × 0.5 to W × 0.7 XP-52ZL/NP52ZL L = W × 0.6 to W × 0.9 XP-53ZL/NP53ZL L = W ×...
  • Page 195 9. Appendix Lens shifting range This projector is equipped with a lens shift function for adjusting the position of the projected im- age by buttons. The lens can be shifted within the range shown below. • See page for lens shift operations and precautions. Description of symbols: V indicates vertical (height of the projected image), H indicates horizontal (width of the projected image).
  • Page 196 9. Appendix Example: When projecting on a 16:10 150" screen using the XP-54ZL lens: According to the "Lens types and throw distance (Aspect ratio 16:10)" (→ page 163), H (screen width) = 323.1 cm and V (screen height) = 201.9 cm Adjustment range in the vertical direction: Upper and lower directions of 0.65 ×...
  • Page 197 9. Appendix 9-2. Compatible Input Signal List HDMI Signal Resolution ( dots ) Aspect Ratio Refresh Rate ( Hz ) Bit Depth Signal Type 640 × 480 4 : 3 SVGA 800 × 600 4 : 3 1024 × 768 4 : 3 1280 ×...
  • Page 198 9. Appendix HDBaseT Signal Resolution ( dots ) Aspect Ratio Refresh Rate ( Hz ) Bit Depth Signal Type 640 × 480 4 : 3 SVGA 800 × 600 4 : 3 1024 × 768 4 : 3 1280 × 720 16 : 9 WXGA 1280 ×...
  • Page 199 9. Appendix *1 Native resolution When inputting signals that are not in native resolution, the thickness of letters and guidelines may be uneven and some colors may run. *2 When the signal format is YCbCr4:2:2, [BIT DEPTH] information is not displayed in [INFO.] → [SOURCE(2)] screen of the on-screen menu.
  • Page 200 9. Appendix 9-3. Specifications Model name A201U-B Method Three primary color liquid crystal shutter projection method Specifications of main parts Liquid crystal Size 1.0" × 3 (aspect ratio: 16:10) panel Pixels 2,304,000 (1920 dots × 1200 lines) (*1) Projection lenses Refer to the specifications of option lens (→...
  • Page 201 9. Appendix Model name A201U-B Usage environment Operating temperature: 32 to 113°F (0 to 45°C) (*5) Operating humidity: 20 to 80% (with no condensation) Storage temperature: 14 to 122°F (−10 to 50°C) Storage humidity: 20 to 80% (with no condensation)
  • Page 202 9. Appendix Option lens (sold separately) Lens model name Specifications XP lenses NP lenses XP-51ZL NP51ZL Throw ratio 0.53–0.65 : 1, F1.94–2.20, f=12.0-14.6 mm XP-52ZL NP52ZL Throw ratio 0.65–0.87 : 1, F1.84–2.25, f=14.4-19.1 mm XP-53ZL NP53ZL Throw ratio 0.86–1.25 : 1, F1.80–2.24, f=19.0-27.6 mm XP-54ZL NP54ZL Throw ratio 1.24–2.01 : 1, F1.80–2.24, f=27.7-44.3 mm...
  • Page 203 9. Appendix 9-4. Cabinet Dimensions Unit: mm (inch) 400 (15.7) 650 (25.6) 300 (11.8) 150 (5.9) * Consult your dealer for installing the projector on the ceiling. To the dealer and the installer Be sure to fasten the ceiling mount fittings securely, using all 6 screw holes.
  • Page 204 9. Appendix 9-5. Pin assignments and signal names of main connectors HDMI 1 IN/HDMI 2 IN Connector (Type A) Pin No. Signal TMDS Data 2+ 2 4 6 8 10 12 14 16 18 1 3 5 7 9 11 13 15 17 19 TMDS Data 2 Shield TMDS Data 2−...
  • Page 205 9. Appendix PC CONTROL Port (D-Sub 9 Pin) Pin No. Signal Unused RxD reception data TxD transmission data Unused Grounding Unused RTS transmission request CTS transmission allowed Unused...
  • Page 206 9. Appendix 9-6. Portrait projection (vertical orientation) Portrait screens from a computer can be projected by installing the projector in a vertical orientation. Precautions during installation • Please do not install the projector in a vertical orientation on top of the floor or table on its own.
  • Page 207 9. Appendix Reference drawings * The drawing showing the dimensional requirements is not an actual stand design drawing. (Unit: mm) 284.5 [Front View] [Side View] a: Intake air / b: Exhaust / c: Screw 6 - M4 / d: Horizontal adjuster ** The example shows the side where the control unit is located facing downwards.
  • Page 208 9. Appendix 9-7. Stacking projectors The projected image brightness can be doubled by gravity stacking up to two projectors without external support. This is called “Stacking Projection”. 2 projectors can be stacked on top of each other for “Stacking” setup. CAUTION: •...
  • Page 209 9. Appendix 9-8. Troubleshooting This section helps you resolve problems you may encounter while setting up or using the projector. Feature of each indicator a. POWER indicator b. STATUS indicator c. LIGHT indicator d. TEMP. indicator Indicator Message (Status message) POWER STATUS LIGHT...
  • Page 210 9. Appendix POWER STATUS LIGHT TEMP. Projector status Powered state ([REF. LIGHT MODE] is [SILENT] or [LONG LIFE]) Blue Green (Light) (Blink* [LENS CALIBRATION] implement request. Status varies Orange Status varies (Blink* Performing the lens calibration Blue Green Status varies (Light) (Blink* Shutter function is activating...
  • Page 211 9. Appendix Indicator Message (Error message) POWER STATUS LIGHT TEMP. Projector status Procedure A button has been The [CONTROL PANEL pressed while the [CON- LOCK] is activated. The TROL PANEL LOCK] is setting must be canceled Blue Orange Status varies activated.
  • Page 212 9. Appendix When the thermal protector is activated: When inside temperature of the projector becomes too high or low, the POWER indicator start to red blink in a short cycle. After this happened, the thermal protector will activate and the projector may be turned off.
  • Page 213 9. Appendix Common Problems & Solutions (→ “Indicator Message” on page 180.) Problem Check These Items Does not turn on or shut • Check that the power cord is plugged in and that the power button on the projector cabinet or the down remote control is on.
  • Page 214 9. Appendix Problem Check These Items Picture is blurred • Adjust the focus. (→ page 29) • Reposition the projector to improve its angle to the screen. (→ page 26) • Ensure that the distance between the projector and screen is within the adjustment range of the lens.
  • Page 215 9. Appendix 9-9. PC Control Codes and Cable Connection PC Control Codes Command Format - A Function Code Data POWER ON POWER OFF INPUT SELECT HDMI1 INPUT SELECT HDMI2 INPUT SELECT HDBaseT INPUT SELECT SDI PICTURE MUTE ON PICTURE MUTE OFF SOUND MUTE ON SOUND MUTE OFF Command Format - B...
  • Page 216 9. Appendix Cable Connection Communication Protocol Baud rate 115200/38400/19200/9600/4800 bps Data length 8 bits Parity No parity Stop bit 1 bit X on/off None Communications procedure Full duplex NOTE: • Depending on the equipment, a lower baud rate may be recommended for long cable runs. PC CONTROL Port (D-Sub 9P) To TxD of PC To RxD of PC...
  • Page 217 This device supports the common ASCII Control Command for controlling our projector and monitor. Please visit our web site for detailed information about the command. https://www.sharp-nec-displays.com/dl/en/pj_manual/lineup.html How to connect with an external device There are two methods to connect the projector with an external device such as a computer.
  • Page 218 9. Appendix Parameters for this device Input command Input terminal Response Parameter HDMI1 hdmi1 hdmi1 or hdmi HDMI2 hdmi2 hdmi2 HDBaseT hdbaset hdbaset or hdbaset1 sdi or sdi1 Status command Response Error Status error:temp Temperature error error:fan Fan trouble error:light Light source trouble errorl:lens Lens trouble...
  • Page 219 9. Appendix 9-11. List of Art-Net DMX parameters Function Behavior Parameter Note POWER 0 – 63 No operation 64 – 191 192 – 255 INPUT No operation 0 – 7 HDMI1 8 – 15 No operation 16 – 23 HDMI2 24 –...
  • Page 220 9. Appendix 9-12. Troubleshooting Check List Before contacting your dealer or service personnel, check the following list to be sure repairs are needed also by referring to the “Troubleshooting” section in your user’s manual. This checklist below will help us solve your problem more efficiently. * Print this page and the next page for your check.
  • Page 221 9. Appendix In the space below please describe your problem in detail. Information on application and environment where your projector is used Projector Signal cable Model number: SHARP standard or other manufacturer’s cable? Serial No.: Model number: Length: inch/m Date of purchase: Distribution amplifier Light module operating time (hours): Model number:...
  • Page 222 Ver.1 10/24...

This manual is also suitable for:

Xp-a201u-b
