LED Condition
Input LED
Green
Off
Output LED
Solid Green
Blinking Green (1Hz)
Off
Blinking Amber (1Hz)
Blinking Green (2Hz)
Solid Amber
OTP: Over Temperature Protection, OVP: Over Voltage Protection, UVP: Under Voltage Protection,
OCP: Over Current Protection
Fan FRU LED
Additional information about fan status can be obtained by the LEDs located on the fan itself.
LED Condition
Off
Green
Amber
Equipment Status
Input within range
Input out of range
FW upgrading
12.3V Main output OK
12.3 Main output in standby mode.
12.3V main output off due to input out of range
Over temp warning
Fan error
FW upgrading
12.3V main output or 12VSB out or range
OTP, OVP, UVP, OCP
Equipment Status
No input power
Fan FRU function normal
Fan FRU abnormal, service is required
S9610-36D Hardware Installation Guide | 23
