Port Overview

Port ID Form Factor
0~35 QSFP-DD
The S9610-36D ports 0-35 (labelled in blue in figure below) will all function normally when
statistics counter is not enabled. Once the statistics counter is enabled, the service ports 1,
17, 19 and 35 (labelled in yellow in figure below) will be disabled and reserved for statistics
functionality. Therefore, when statistics counter is enabled, there will only be 32 service
ports available.
The S9610-36D has the following 400G ports with the power capacity to support OpenZR+
and 400ZR for WAN and long-haul applications. With statistic counter disabled, ports 0-5,
10-13, 18-21, 26-29, 34-35 (labelled in orange) can support OpenZR+ and 400ZR. With
statistic counter enabled, ports 1, 17, 19, and 35 are reserved and will be disabled (labelled
in yellow), therefore, the ports 0, 2-5, 10-15, 18, 20-21, 26-31 (labelled in orange) can
support OpenZR+ and 400ZR.
Maximum Support Distance
Up to 372.82mi (600km)
Figure 8.
Figure 9.
S9610-36D Hardware Installation Guide | 9
Support Speed
40/100/400G
