- Page 1 S9600-72XC Open Aggregation Router Hardware Installation Guide R1.0...
-
Page 2: Table Of Contents
11 Initial System Setup ......................24 12 Cable Connections ......................25 Connecting the USB Extender Cable ..................25 Connecting a Cable to the ToD Interface................25 Connecting the GNSS Interface ................... 26 Connecting the 1PPS Interface .................... 26 S9600-72XC Hardware Installation Guide | i... - Page 3 Connecting the 10MHz Interface ..................27 Connecting the Transceiver ....................27 13 Cautions and Regulatory Compliance Statements .............. 29 Cautions and Regulatory Compliances ................29 S9600-72XC Hardware Installation Guide | ii...
-
Page 4: Overview
5G mobile Ethernet network. Due to its versatility, the S9600-72XC can be positioned in different parts of the network to perform aggregation, such as in the backhaul to aggregate BBU pooling or even as a Broadband Network Gateway (BNG) within the central office. -
Page 5: Preparation
PC with terminal emulation software. Refer to the "Initial System Setup" section for details. • Baud rate: 115200 bps • Data bits: 8 • Parity: None • Stop bits: 1 • Flow control: None S9600-72XC Hardware Installation Guide | 2... -
Page 6: Installation Environment Requirements
1.1 inches (2.7cm). Therefore, to accommodate the fan and power supply handles, a minimum space clearance of 6 inches (15.2cm) is needed at the back of the S9600-72XC. A total minimum reserve depth of 30 inches (76.2cm) is required. Figure 1. -
Page 7: Preparation Check List
AC version: 100 – 120V, 12Ax2 ampere maximum 200-240V, 7.5Ax2 ampere maximum Installation spacing requirement S9600-72XC is 2RU (3.45”/8.8cm) in height, 19” (48.3cm) in width, and minimum reserve depth of 30 inches (76.2cm) Thermal requirement S9600-72XC working temperature is 0 to 45°C (32°F to 113°F),... -
Page 8: Package Contents
0.03lbs(16g)/1 pcs 24.7”x 1.7” x 0.8” Adjustable Mounting 6.79lbs(3.08kg)/2pcs (626.3 x 43.8 x 20.8mm) 2 pcs Rail (for 4 post) 3.39lbs(1.54kg)/1pcs (21”~35” rack depth) SMB To BNC 2 pcs 3.94”~11.8" (10~30cm) 0.035lbs (16g)/pcs Converter Cable S9600-72XC Hardware Installation Guide | 5... -
Page 9: Component Physical Information
0.7lbs (318g) SMB To BNC Converter Cable 0.07lbs (32g) 17.16” x 24” x 3.45” S9600-72XC (W x D x H) (436 x 609.6 x 87.6mm) Dimension PSU (W x D x H) 1.99” x 12.64” x 1.58” (50.5 x 321 x 40.2mm) Fan (W x D x H) 3.15”... -
Page 10: Identifying Your System
4 Identifying Your System S9600-72XC Overview Figure 4. PSU Overview Power supply unit (PSU) with 1+1 Redundancy. Hot swappable, field replaceable unit (FRU). AC Version: Figure 5. DC Version: S9600-72XC Hardware Installation Guide | 7... -
Page 11: Fan Overview
Figure 6. Fan Overview 3+1 Redundant, hot swappable, field replaceable unit (FRU). Figure 7. Port Overview S9600-72XC Hardware Installation Guide | 8... - Page 12 Port ID Form Factor Maximum Support Distance Support Speed 0 ~ 63 SFP28 Up to 6.2mi (10km) 1GE/10GE/25GE 64~71 QSFP28 Up to 6.2mi (10km) 40GE/100GE Figure 8. S9600-72XC Hardware Installation Guide | 9...
-
Page 13: Rack Mounting
Make sure the locking screw of the inner rail is positioned at the front of the chassis. 2.2 After the attachment pins are secured to the inner rail, lock the inner rail to the chassis using two M4 screws (one on each chassis side). S9600-72XC Hardware Installation Guide | 10... - Page 14 4.4 Push the blue release tab on each rail to unlock the rails and slide the chassis all the way into the rack. 4.5 Lock the chassis into place by using the screw on the front of the inner rail. S9600-72XC Hardware Installation Guide | 11...
- Page 15 Figure 12. S9600-72XC Hardware Installation Guide | 12...
-
Page 16: Installing Fan Modules
5. An audible click will be heard when the fan module is installed correctly. The fan module will not go in all the way if it is installed in the wrong direction. Figure 15. S9600-72XC Hardware Installation Guide | 13... -
Page 17: Installing Power Supply Units
2. While holding down the release tab, grip the PSU's handle and firmly pull it out of the power bay. DC Version: AC Version: Figure 17. 3. Align the new PSU with the power bay, ensuring the PSU’s power connector is in the correct S9600-72XC Hardware Installation Guide | 14... - Page 18 4. Carefully slide the new PSU into the power bay and gently push until it is flush with the case. 5. An audible click will be heard when the PSU is installed correctly. The PSU will not go in all the way if it is in the wrong direction. Figure 18. S9600-72XC Hardware Installation Guide | 15...
-
Page 19: Grounding The Router
3. Insert the exposed grounding wire all the way into the hole of the grounding lug (provided with package contents). 4. Using a crimping tool, firmly secure the grounding wire to the grounding lug. Figure 19. S9600-72XC Hardware Installation Guide | 16... - Page 20 Figure 20. 6. Using 2 M4 screws and 4 washers (provided with the package contents), firmly lock the grounding lug to the designated grounding location on the router. Figure 21. S9600-72XC Hardware Installation Guide | 17...
-
Page 21: Connecting Power
Also, please ensure that both PSUs have been properly installed before powering up the equipment, as the S9600-72XC is designed to support 1 + 1 power redundancy. 2. Attach the DC power cables to the lugs. - Page 22 (Top picture). Secure the one-hole lugs (with the DC power cable attached) to the terminal block (Middle picture). Put plastic cover back on terminal block S9600-72XC Hardware Installation Guide | 19...
-
Page 23: Ac Version
Also, please ensure that both PSUs have been properly installed before powering up the equipment, as the S9600-72XC is designed to support 1 + 1 power redundancy. S9600-72XC Hardware Installation Guide | 20... - Page 24 If connected correctly, when turned on, the LED on the PSU will light up with a solid Green color designating normal operation. If only a 110VAC power source is available, the S9600-72XC can still be powered using both PSUs (1000 watts each for a total output of 2000 watts).
-
Page 25: Verifying System Operation
Solid Amber One or more FAN module(s) need service Blinking Amber Reserved No Power Solid Green PSU 0 is working well Blinking Green Reserved Solid Amber PSU 0 fail (PSU0 need service) Blinking Amber Reserved S9600-72XC Hardware Installation Guide | 22... -
Page 26: Psu Fru Led
Additional information about fan status can be obtained by the LEDs located on the fan itself. LED Condition Equipment Status No input power to all power supplies Green Fan FRU function normal Amber Fan FRU abnormal, service is required S9600-72XC Hardware Installation Guide | 23... -
Page 27: Initial System Setup
USB cable provided in the packaging contents. Download the suitable driver for your operating system (OS) using the URL below: • https://www.silabs.com/products/development-tools/software/usb-to-uart-bridge- vcp-drivers • https://www.silabs.com/ and search for CP210X Figure 28. S9600-72XC Hardware Installation Guide | 24... -
Page 28: Cable Connections
1. Connect one end of a straight-through Ethernet cable to the GNSS unit 2. Connect the other end of the straight-through Ethernet cable to the port marked “TOD” located on the front panel of the router. S9600-72XC Hardware Installation Guide | 25... -
Page 29: Connecting The Gnss Interface
Connect an external 1PPS cable with an impedance of 50 ohms to the port labelled “ 1PPS”. If the connector is not same type as SMB, please use the converter cable in the accessory list to convert to BNC type. S9600-72XC Hardware Installation Guide | 26... - Page 30 It is recommended to use hook-and-loop style straps to secure and organize the cables. • For easier management, label each fiber-optic cable and record its respective connection. • Maintain a clear line of sight to the port LEDs by routing the cables away from the LEDs. S9600-72XC Hardware Installation Guide | 27...
- Page 31 3. Place the bail (wire handle) in the unlocked position and align the transceiver with the port. 4. Slide the transceiver into the port and gently push until it is secured in place. An audible click can be heard when the transceiver is secured in the port. S9600-72XC Hardware Installation Guide | 28...
- Page 32 Avertissement: Ne pas utiliser d’instruments optiques pour voir la sortie du laser. L’utilisation de instruments optiques pour afficher la sortie laser augmente les risques oculaires. Utilisez uniquement UL/CSA, IEC/EN60825-1 /-2 reconnu modules enfichables. S9600-72XC Hardware Installation Guide | 29...
- Page 33 édicté par le ministère des Communications du Canada Class A ITE Notice This equipment is compliant with Class A of CISPR 32. In a residential environment this equipment may cause radio interference. S9600-72XC Hardware Installation Guide | 30...
- Page 34 This is a Class A product based on the standard of the Voluntary Control Council for Interference by Information Technology Equipment (VCCI). If this equipment is used in a domestic environment, radio disturbance may arise. When such trouble occurs, the user may be required to take corrective actions. S9600-72XC Hardware Installation Guide | 31...
- Page 35 www.ufispace.com...
