Summary of Contents for Hisense 55GM60AE
- Page 1 Bar code...
- Page 2 Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time. English RSAG2.025.8054SS A...
- Page 3 Declaration Any content and service accessed through this device, while only intended for individual non- commercial use, shall be the property of the applicable third party and subject to protection by regulations and laws on copyright, patent, trademark and other intellectual property rights. No part of such content and service may be modified, duplicated, published, uploaded, distributed, translated, marketed, or used to make and distribute products derived from it without the prior permission of the content owner or service provider.
- Page 4 Important Safety Precautions This symbol alerts user about the ATTENTION presence of a dangerous voltage not RISK OF SHOCK isolated inside the product which can ELECTRIC be sufficiently powerful to constitute a risk of electrocution. Do not open the back cover. In no case the user is allowed to operate This symbol alerts user about the inside the device.
- Page 5 Safeguards Please read the following safeguards for your device and retain for future reference. Always follow all warnings and instructions marked on the device. 1. A note about safety and operating instructions Read and follow all safety and operating instructions, and retain them safely for future reference.
- Page 6 9. Overloading Do not overload wall outlets and extension cords as this can result in a risk of fire or electric shock. 10. Object and Liquid Entry Never push objects of any kind into this device through openings as they may touch dangerous voltage points or short-out parts that could result in fire or electric shock.
- Page 7 16. Fire The product should be situated away from naked flame sources such as lighted candle. 17. Off-gassing The device smells of plastic is normal and will dissipate over time. Incorrect replacement of the battery may lead to the risk, including the replacement of another similar or the same type.
-
Page 8: Table Of Contents
CONTENTS Contents ........................1 Accessories List......................2 Wall Mount (Optional) ....................2 Remote Control ......................5 Control Panel ......................7 Terminal Introduction ....................8 Initial Startup......................10 System Menu......................11 Serial Protocol ......................12 Miscellaneous ......................15 Specifications ......................16 Other information ..................... 18... -
Page 9: Accessories List
4. Before hanging the machine, please confirm that the wall-mount bracket is installed securely without looseness. VESA wall mount Diameter of wall- Model standard (mm) mount screw (mm) 50GM60AE 200x200 55GM60AE 400X200 65GM60AE 400×400... - Page 10 Wall mount position Warning: • At the four wall-mounting positions shown in the figure, the screw installation depth H should be 6-10mm from the bottom of sunken pit in the rear shell. Wall mount Cushion block Screw Vertical beam Rear shell...
- Page 11 5. This product can be both used in horizontal mode and vertical mode. The horizontal installation is shown in Figure 1, and the vertical installation state is shown in Figure 2. Figure 1: Horizontal instllation Figure 2: Vertical instllation [Note] ·...
-
Page 12: Remote Control
Remote Control Lock Open the Settings menu Forbid remote control to control device Adjust brightness level Volume up/down Open White Balance menu Open CMS(Content Man- agement System) Set the Voice mode [Note] · When the remote control is locked, press LEFT>OK>OK>LEFT to unlock it. Warning: Operation of this equipment in a residential environment could cause radio interference. - Page 13 Battery replacement method Disconnect the battery cover from the remote control at the battery cover buckle and open the battery cover. Insert two AAA 1.5V alkaline batteries. Note that the positive (+) and negative (-) terminals of the batteries must match the positive (+) and negative (-) terminals in the battery case.
-
Page 14: Control Panel
Control Panel Remote sensor / Power indicator Name/Operation Function Receive signals transmitted by the remote control via this Remote receiver window. When the machine is on, the indicator light is blue; when it Indicator enters sleep mode, the indicator light is red. [Note] •... -
Page 15: Terminal Introduction
Terminal Introduction AC INPUT [Note] · The rear view is for reference only, please subject to the actual product. · RS232 port: It is for serial communication control of the machine. · It is possible that some external devices cannot be connected to the machine due to individual difference. - Page 16 Port Name Function descriptionunction It can be used to connect an external device with HDMI port, HDMI such as STB, player, or PC with HDMI output. USB standard port is provided with this machine; it can also be used to connect a standard USB device, such as hard disk drive and USB flash drive.
-
Page 17: Initial Startup
Initial Startup 1 Startup/Shutdown Connect the power cord of the machine to a 100-240V AC power outlet. · Gently press the power switch of the machine toward to turn on the machine. · In power-on state, press the STANDBY key on the remote control;... -
Page 18: System Menu
System Menu To open the System menu: SETTING key to enter the Setting interface, then select the System menu. Press the Menu introduction: Time Settings: Set the local time. · Time Zone Selection: Set the time zone. The default state is Poland UTC+1. ·... -
Page 19: Serial Protocol
Serial Protocol Serial Port State: When the serial port is open, the machine can receive serial port commands sent by the external controller. See the table below for the specific command protocol: . Baud rate: 9600 . Control part: PC→TV . - Page 20 PC to TV DD FF 00 07 C1 27 00 00 XX XX XX BB CC Under Data, the first XX is the equipment number; the second XX is the set value of TV to PC AB AB 00 07 C1 27 00 00 XX XX XX CD CD volume volume;...
- Page 21 [Note] BoardID ranges from 01 to FF, supporting networking of 255 machines. 00 is the · broadcast address; commands sent from this ID will be executed by all machines but will not be returned. For commands received by all TV terminals, when they are returned to PC, the ·...
-
Page 22: Miscellaneous
Miscellaneous 1 Troubleshooting Before preparation for repair, please check the following table to see if the cause of problem you are encountering can be found. If the problem still exits when you confirm that you are operating the product in strict accordance with the this manual, you can consider contacting professional service personnel for repair. -
Page 23: Specifications
Specifications Product name Digital Signage Model 50GM60AE 55GM60AE 65GM60AE Size(mm) (W×H×D)excluding 1122×647×70 1236×715×71 1456×834×71 base Weight(kg) excluding base 13.5 15.5 21.5 Visual picture diagonal size(cm) 100-240V~50/60Hz 100-240V~50/60Hz 100-240V~50/60Hz Power supply 1.8A 2.0A 2.4A Model W2NM2510 Frequency 2.4~2.4835GHz Wireless Range LAN Module... - Page 24 Signal Formats Supported by HDMI Port 640×480, 800×600, 1024×768, 1280×720, 1280×1024, 1360×768, RGB/60Hz 1366×768, 1440×900, 1600×900, 1920×1080, 3840×2160@60HZ YUV/50Hz 576i, 576p, 720p, 1080i, 1080p YUV/60Hz 480i, 480p, 720p, 1080i, 1080p Computer Signal Formats Supported by VGA Port Resolution Refresh Rate Resolution Refresh Rate 640×480...
-
Page 25: Other Information
Other information FCC Notice This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protec- tion against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
