Read the manual carefully and ensure you have fully understood its
contents before operating this device for the first time.
English

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 75B4E30T and is the answer not in the manual?

Questions and answers

Related Manuals for Hisense 75B4E30T

Summary of Contents for Hisense 75B4E30T

  • Page 1 Read the manual carefully and ensure you have fully understood its contents before operating this device for the first time. English...
  • Page 3 Declaration Declaration Any content and service accessed through this device, while only intended for individual non-commercial use, shall be the property of the applicable third party and subject to protection by regulations and laws on copyright, patent, trademark and other intellectual property rights.
  • Page 4 Safety Instructions This symbol indicates high voltage CAUTION is present inside. It is dangerous RISK OF SHOCK to make any kind of contact with ELECTRIC any inside part of this product. CAUTION: To reduce the risk of electric shock, do not remove cover This symbol alerts you that (or back).
  • Page 5 Safety Instructions Safeguards Please read the following safeguards for your device and retain for future reference. Always follow all warnings and instructions marked on the device. 1. A note about safety and operating instructions Read and follow all safety and operating instructions, and retain them safely for future reference.
  • Page 6 Safety Instructions 10. Object and Liquid Entry Never push objects of any kind into this device through openings as they may touch dangerous voltage points or short-out parts that could result in fire or electric shock. Never spill liquid of any kind on or into the device. 11.
  • Page 7 Safety Instructions 18. Stability Hazard. The device may fall, causing serious personal injury or death. To prevent injury, this device must be securely attached to the floor/wall in accordance with the installation instructions. Incorrect replacement of the battery may lead to the risk, including the replacement of another similar or the same type.
  • Page 8 Safety Instructions...
  • Page 9 *The company reserves the right to install updated Software versions to improve the performance ofthe appliance. Place and date of issue (of this DoC): QingDao 2020/7/21 Signed by or for the manufacturer: Hisense Commercial Display Co., Ltd. Address: No. 218 Qianwangang Road, Economy & Technology Development Zone, Qingdao, China...

  • Page 10: Table Of Contents

    Contents Unpacking and Installation ..................1 1.1. Unpacking ....................1 1.2. Package Contents ..................1 1.3. Installation Notes..................2 1.4. Mounting on a Wall ..................2 Parts and Functions ....................4 2.1. Control Panel ...................4 2.2. Input/Output Terminals ................5 2.3. Remote Control ..................6 Connecting External Equipment ................9 3.1.

  • Page 11: Unpacking And Installation

    Unpacking and Installation Unpacking and Installation 1.1. Unpacking • This product is packed in a carton, together with the standard accessories. • Any other optional accessories will be packed separately. • Move the display by at least two (2) adults. •...

  • Page 12: Installation Notes

    Unpacking and Installation 1.3. Installation Notes • Only use the power cable provided with this product. If an extension cord is required, please consult your service agent. • The product should be installed on a flat surface, or the product may tip over. Leave a space between the rear of the product and the wall for proper ventilation.
  • Page 13 Unpacking and Installation 1.4.1. VESA Grid 75B4E30T/86B4E30T 600(H) x 400(V) mm NOTE: The appearance and color of the product are subject to the material object. The picture is for reference only. 1. Lay a protective sheet on a table, which was wrapped around the display when it was packaged, beneath the screen surface so as not to scratch the screen face.

  • Page 14: Parts And Functions

    Parts and Functions Parts and Functions 2.1. Control Panel MUTE INPUT MENU NOTE: The appearance and color of the product are subject to the material object. The picture is for reference only. ] button ] button Turn the display on or put the display Move the highlight bar up to adjust to standby.

  • Page 15: Input/Output Terminals

    Parts and Functions 2.2. Input/Output Terminals MICRO SD USB 1 DC 5V 0.5A(MAX) USB 2 DC 5V 1A(MAX) HDMI 2(4K@60Hz) HDMI 1(4K@60Hz) AC INPUT AUDIO OUT AUDIO IN RS232 NOTE: The appearance and color of the product are subject to the material object. The picture is for reference only.

  • Page 16: Remote Control

    Parts and Functions 2.3. Remote Control Access the OSD menu. [INFO] button 2.3.1. General functions Show Information OSD. ] MUTE button Mute or restore volume. ] BACK button Return to the previous page or exit from the previous function. ]VOLUME button Turn up the volume.
  • Page 17 Parts and Functions 2.3.2. Inserting the Batteries in the Remote Control The remote control is powered by two 1.5V AAA batteries. To install or replace the batteries: 1. Press and then slide the cover to open it. 2. Insert the batteries with the correct polarity (+) and (–).
  • Page 18 Parts and Functions 2.3.4. Operating range of the remote control Point the top front of the remote control to the remote sensor on the display when you press the buttons. NOTE: The remote control may not function properly when the remote control sensor on the display is under direct sunlight or strong illumination, or when there is an object between the remote control and...

  • Page 19: Connecting External Equipment

    Connecting External Equipment Connecting External Equipment 3.1. Connecting External Equipment (DVD/VCR/VCD) 3.1.1. Using HDMI video input HDMI 2(4K@60Hz) HDMI 1(4K@60Hz) DVD / VCR / VCD HDMI OUT HDMI IN 3.2. Connecting a PC 3.2.1. Using HDMI input HDMI 2(4K@60Hz) HDMI 1(4K@60Hz) HDMI OUT HDMI IN 3.2.2.

  • Page 20: Connecting Usb

    Connecting External Equipment 3.2.3. Using network interface WiFi INTERNET 3.2.4. Connecting an external audio device HDMI 1(4K@60Hz) HDMI 2(4K@60Hz) AUDIO OUT RS232 AUDIO OUT HDMI 2 3.3. Connecting USB USB 1 DC 5V 0.5A(MAX) USB 2 DC 5V 1A(MAX)

  • Page 21: Operation

    Operation Operation 4. If you select the empty playlist, the application will guide you to choose media sources. 4.1. Media Player All media files should be located in Instructions the root directory. For example: - Video at /root/movies/ 1. The front page of the media player, - Photos /root/pictures/ this page contains three items: - Music /root/music/...
  • Page 22 Operation 7. After you start editing the playlist, 9. Choose the desired file information you will see the following screen. in play list and press [ ] button, Source - storage device files. you can get information detail. Playlist - playlist files. 7-1 in a scroll bar can help you to perform the following items：...

  • Page 23: Pdf Reader Play

    Operation 12. On the first page of “Settings”, this 3. Select “Compose” on home page, page contains three parts: first you should choose one playlist “Repeat Mode”, “Slideshow Effect” to edit from File 1 to File 7. and “Effect Duration”. The pencil icon means the playlist is Repeat Mode: playback mode.
  • Page 24 Operation 6. You could rename the playlist, just 8. If you choose “Sort” in the slidebar, input new name after pressing the you can change the order of files one “OPTIONS” key on the remote by one. control. 9. Select “Settings” on home page, this 7.

  • Page 25: U Disk Files Playback And Copy Instructions

    Operation 4.3. U disk Files Playback 7. After selecting the directory to copy to, press the [ ] left / right and Copy Instructions buttons on the remote control to 1. U disk can only have one partition. select Paste or Cancel, as shown The format must be FAT32 and the below.

  • Page 26: Using Cms 3.1

    Operation 4.4. Using CMS 3.1 1. System Requirement System Requirement Operating Windows 7,8,10 (32/64 Systems bit) ----Functions 2.5GHz CPU or faster Hard Disk 100GB Network card 10/100/1000 Ethernet card 2. Application • CONTENT: design your layout of Installation wizard advertisement (AD) Auto detect system language •...

  • Page 27: Osd Menu

    OSD Menu OSD Menu Operation on the OSD Menu Column 2, 3 or Column 1 Column 2 Column 1, 3 Remarks Column 2, 2 Network Switch address Connection [DHCP / Static type Ethernet IP address Netmask address Gateway WiFi address Add network Refresh Switch...
  • Page 28 OSD Menu [ Standard (9300K), Color Cool (12000K), Temperature Warm (6500K), Picture User ( R/G/B) ] Mode Full/ Aspect ratio Real/4:3/14:9 Eye Protect Volume & [ON/OFF] Mode Picture Volume 0~100 Audio Source [HDMI / Line in] [ Standard, Sound Mode News, Music, Audio Movie,User ]...
  • Page 29 OSD Menu HDMI 2.0/1.4 Version 1. Set to ON, HDMI 1/HDMI 2/OPS automatically cuts to another source when no signal is received. This feature is available when the current source is HDMI HDMI after the machine is Failure of [ON/OFF] started.
  • Page 30 OSD Menu 10 Minutes 20 Minutes 30 Minutes 1 Hour Sleep Time 1.5 Hour 2 Hours 1 Second 5 Seconds 10 Seconds Auto Sleep 30 Seconds 60 Seconds Sleep Mode Screensaver Supported file type： 1. Photo: “.png”, “.jpg”“.jpeg”, “.bmp” 2. Video: “.dat”, Screensaver “.vob”, “.ts”, Source...
  • Page 31 OSD Menu [Beijing/ Calcutta/ Harare/Karachi /Brazzaville/ Beirut/ Jerusalem/ Time zone Tehran / Date & time Baghdad/ Ulaanbaatar/ Damascus/ Sydney /Paris/ Rome/London/ Dubai/Tokyo] NTP Server Local Update From OFF to ON, a System pop-up prompts: “This [Switch] update Online Update function is valid, the system needs to be restarted.

  • Page 32: Compatibility Of The Usb Device

    Compatibility of the USB device Compatibility of the USB device Format of the USB multi-media coder-decoder Video decoding Video Type coder- Container Decoding Coding Channel Remarks decoder Supported size in a range from 48x48 pixels to File 1920X1080 pixels MPEG1/2 MPEG1/2 format: Max.
  • Page 33 Compatibility of the USB device Supported picture size: from 48x48 pixels to 1920x1080 pixels File Max. frame rate:30fps format: H.264 H.264 Max. bit rate: MKV, 57.2Mbps MP4, 3GP Audio coder-decoder: MP2, MP3, AAC, (1) Not support MBAFF Supported picture size: frame 48x48 pixels to 1920x1080 pixels File...
  • Page 34 Compatibility of the USB device Picture decoding Type Picture coder- Picture Decoding Coding Channel Remarks decoder Decode: Resolution ratio 48X48 to 8176X8176 (1) Row-by-row scanning is not JFIF file format File format: supported. JPEG 1.02 JPG, JPEG (2) Software supports SRGB JPEG.

  • Page 35: Input Mode

    Input mode Input Mode HDMI computer mode (75B4E30T/86B4E30T) Available Resolution Standard Refresh Rate Pixel Rate Aspect Ratio Resolution H pixel V line 60 Hz 25.175 MHz 75 Hz 31.5 MHz WVGA 70 Hz 28.32 MHz SVGA 60 Hz 40 MHz...
  • Page 36 Input mode Computer mode (75B4E30T/86B4E30T) Available Resolution Standard Refresh Rate Pixel Rate Aspect Ratio Resolution H pixel V line 60 Hz 25.175 MHz 75 Hz 31.5 MHz WVGA 70 Hz 28.32 MHz SVGA 60 Hz 40 MHz 1024 60 Hz...

  • Page 37: Cleaning And Troubleshooting

    Cleaning and Troubleshooting Cleaning and Troubleshooting 8.1. Cleaning Caution When Using the Display • Do not bring your hands, face or objects close to the ventilation holes of the display. The top of the display is usually very hot due to the high temperature of exhaust air being released through the ventilation holes.

  • Page 38: Troubleshooting

    Cleaning and Troubleshooting 8.2. Troubleshooting Symptom Possible Cause Remedy No picture is displayed 1. The power cord is 1. Plug in the power cord. disconnected. 2. Make sure that the power 2. The main power switch is switched on. switch on the back 3.
  • Page 39 Cleaning and Troubleshooting Some picture Some pixels of the This display is designed using an elements do not light display are off. extremely high level of precision technology: however, sometimes some pixels of the display may not display. This is not a malfunction. After-Images can A still picture is Do not allow a still image to be...

  • Page 40: Technical Specifications

    Technical Specifications Technical Specifications Display: Specifications Item 75B4E30T 86B4E30T Screen Size (Active Area) 75 inches(189 cm) 86 inches(217 cm) Aspect Ratio 16:9 16:9 Number of pixels 3840 (H) x 2160 (V) 3840 (H) x 2160 (V) Pixel pitch 0.4296 (H) x 0.4296 (V) 0.4935 (H) x 0.4935 (V)
  • Page 41 Output power (max) 5.25 ~ 5.35 GHz (DFS bad) 14 dbm 5.47 ~ 5.725 GHz (DFS/TPC band) 14 dbm 5.725 ~ 5.825 GHz (for Non EU) 14 dbm Model 75B4E30T 86B4E30T Scale A+++ -> D A+++ -> D (A++ -> E or A+++ -> D)
  • Page 44 European Energy Efficiency QR Code 75B4E30T 86B4E30T 2020 © All rights reserved. Specifications are subject to change without notice. Q41G75M166101C...
