EXTERNAL RS232
CONTROL GUIDE
DM66D/GM50D SERIES
INTRODUCTION
Our users can control a Hisense display from an external source via RS-232. This user guide will provide
all of the command structures and system parameters required to confidently control Hisense
commercial displays via a PC or a 3rd party control system.
1
www.hisense-b2b.com
Advertisement
Related Manuals for Hisense DM66D Series
Summary of Contents for Hisense DM66D Series
- Page 1 DM66D/GM50D SERIES INTRODUCTION Our users can control a Hisense display from an external source via RS-232. This user guide will provide all of the command structures and system parameters required to confidently control Hisense commercial displays via a PC or a 3rd party control system.
- Page 2 FORMATS HISENSE RS232 commands are HEX codes, not ASCII format. Where applicable, codes contain the ID of the screen you are trying to control. A value of “00” will broadcast the command to all of the screens connected to the RS232 port, for this case, there is no feedback from devices.
-
Page 3: Connectivity Diagram
DM66D SERIES - 24/7 DIGITAL SIGNAGE GM50D SERIES - 18/7 DIGITAL SIGNAGE Connectivity Diagram RS232 Connectivity Illustration The following graphs illustrate the connectivity between a PC and the device. There is already a RJ45-RS232 cable in box, if you’d like to use USB port on PC, you may want to prepare a USB-RS232 cable in advance, please note that the DB-9 connectors of the two cables should be male/female in pairs for this case. - Page 4 RX 5 TX 8 Female for PC RS232 IN Dispaly Method 2 :Using attachment lines Included in the box – 1 x RJ45(Male) – DB-9F(Female)-RS 232 cable Please use table below when wiring a cable: Pin out Connection RJ45(Male) DB-9F(Female) www.hisense-b2b.com...
-
Page 5: Command Format
BB yy BB CC BB yy CD CD Tips: The range of this command’s When TV is in standby sate, ID is 0x01-0x34. send this command will get one feedback from TV, once TV starts up, it will send feedback www.hisense-b2b.com... - Page 6 23.Jan.2 AB AB 00 09 C1 1C 00 00 xx zz zz yy BB CC DDFF0009C11C000001170102C1BB zz zz yy CD CD zz zz zz = FF FF FF when error zz zz zz = Year Month Day www.hisense-b2b.com...
- Page 7 BB CC 0x03 yy CD CD DDFF0007C13B00000103FFBBCC current source must be: DP, VGA, HDMI, PC, DVI zz = 00 - full, 01 - 16:9, 02 - 4:3, 03 - scaling 1, 04 - scaling 2, 05 - point to point www.hisense-b2b.com...
- Page 8 CD CD zz: volume zz zz: 05 01 - PC, 05 02 - DVI, 05 03 - DP, 05 04 - HDMI2, 05 05 - HDMI1, 08 01 - VGA zz: 00 - power on, FF - power www.hisense-b2b.com...
- Page 9 - DNS Query DD FF 00 06 C1 FE 00 00 xx yy DDFF0006C1FE00000138BBCC AB AB 00 07 C1 FE 00 00 xx zz Device BB CC yy CD CD Temperatur zz: temperature in centigrade www.hisense-b2b.com...
- Page 10 DD FF 00 06 C1 FE 00 01 64 5C BB AB AB 00 06 C1 FE 00 01 xx BB CC zz…zz yy CD CD zz…zz: brand. ex: hisense (ASCII) Query DD FF 00 06 C1 FE 00 02 xx yy...
- Page 11 = 01 - freeze; 00 – unfreeze www.hisense-b2b.com...
- Page 12 www.hisense-b2b.com...
