INSTALLATION GUIDE

Hisense Laser TV Display Screen
Before you install this product, read this guide completely and
make sure you understand all of the content.
ENGLISH
ES-G1835M8

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Laser TV Display Screen and is the answer not in the manual?

Questions and answers

Related Manuals for Hisense Laser TV Display Screen

Summary of Contents for Hisense Laser TV Display Screen

  • Page 1: Installation Guide

    INSTALLATION GUIDE Hisense Laser TV Display Screen Before you install this product, read this guide completely and make sure you understand all of the content. ENGLISH ES-G1835M8...

  • Page 2: Product Description

    Product Description The Hisense Laser TV Display Screen has a bezel trim and is designed to be used in rooms where the ceiling light cannot be moved. Maintaining the Screen Dust, dirt and scratches on the screen will affect how images appear. Follow the instructions below to properly maintain the screen.
  • Page 3 Hardware and Parts List for Screen Make sure you have all of the parts shown below before you begin the installation procedure. Name Picture Qty. No. Name Picture Qty. Elbow Joints Horizontal Frame (Spring inserted into the (the side with an arc frame already) edge is front) Left/Right Vertical...

  • Page 4: Frame Assembly

    Frame Assembly Note: The installation space should be at least 5m x 3m( 196 7/8 inches x 118 1/8 inches). ≥5m (196 7/8 inches) ≥3m (118 1/8 inches) Place the Cloth liner(O) sponge on clean area on the ground to assemble the screen. 1.
  • Page 5 Insert the two vertical short frames (C) into the elbow joint (A) as shown in the diagram below. Next, fasten the four angles with the M5x6 Screws (H). Make sure all four corners are p r o p e r l y i n p l a c e t o f o r m a perfect square.
  • Page 6 Screen Material Installation Please read this important note before proceeding with the installation process of the material: Before handling the StarBright CLR® material(P), put on the supplied pair of white gloves(N) to avoid leaving fingerprint marks, dust or oil from your hands on the surface of the material(Figure 1). The StarBright CLR® material(P) is very delicate and should be handled with extreme care.
  • Page 7 component of B and F down Tip:Make sure the back of the screen material is facing up as shown in this illustration. Align the corner component of B and F 6. With one of the springs securely inside the groove of the frame, use the spring hook(K) to attach the spring to the hole located on the outer edge of the screen material.
  • Page 8 Repeat until all of the springs are Use the spring hook (k) to attach the Stretch the screen material in the installed. 2 springs to the hole located on each direction of the arrowhead. side of the screen material’s outer edge.
  • Page 9 Edge Trim Installation Place the Edge Trim(D) along the four edges of the screen material corner. (Note: The logo should be positioned on the bottom frame). Place all the trim pieces along the edge of screen material. Adjust the trim so that the top and bottom trim pieces are touching and show no gaps in the center.

  • Page 10: Front Side

    4. Slant the support rod and make it clip into the groove of upper and bottom frames. Make one end of the rod stay still and push the other end to the center until support rod is perpendicular to the frames. Push Ending condition Initial condition...

  • Page 11: Installing The Wall Mount Brackets

    Installing the Wall Mount Brackets Check the Type of Wall You Have Solid concrete or Drywall with studs? concrete block? Perfect! Perfect! Minimum wood stud size: common 2 x 4 in. (51 x Minimum solid concrete thickness: 8 in. 102 mm) nominal 1½ x 3½ in. (203 mm) (38 x 89 mm) Minimum concrete block size: 8 x 8 x 16 in.
  • Page 12 Install the Wall Mount Brackets NOTE: Make sure you have your paper template, pencil, tape and screwdriver. 1. Starting from the top of your TV stand, add 73 inches(1.85m) above it to get the height of the top of the paper template. Mark the height onto the wall.
  • Page 13 Insert anchors CAUTION: All screws MUST BE firmly tightened to prevent unwanted movement of the brackets. Make sure the brackets are securely fastened to the wall before continuing on to the next step. 7. Attach the upper and lower parts of the wall bracket wands with the screws and bolts. Make sure the two parts are aligned and firmly tighten the screws.
  • Page 14 Hang the Screen 1. We strongly recommend that two people handle this screen when moving it. Be sure to use gloves(included) to protect the screen from grease, sweat and dirt. 2. Place the assembled screen vertically on the ground. Look down on the screen, if the material is black it is in the correct direction and ready for mounting on the wall.
  • Page 15 If the screen is higher than the image, then rotate the wands clockwise and move the screen down. If the screen is lower than the image, then rotate the wands counterclockwise and move the screen up. After you've completed adjusting the screen height, remove the handles. Fold and rest the wands on the screen bracket on the bottom of the screen.
