Global Positioning System (GPS) – Underwriters Laboratories, Inc. Statement
Underwriters Laboratories Inc. ("UL") has not tested the performance or reliability of the Global Positioning
System ("GPS") hardware, operating software or other aspects of this product. UL has only tested for fire, shock or
casualties as outlined in UL's Standard(s) for Safety.UL60950-1 Certification does not cover the performance or
reliability of the GPS hardware and GPS operating software. UL MAKES NO REPRESENTATIONS, WARRANTIES OR
CERTIFICATIONS WHATSOEVER REGARDING THE PERFORMANCE OR RELIABILITY OF ANY GPS RELATED
FUNCTIONS OF THIS PRODUCT.

RS232 9-Pin Functions of the Female End Connector

The following table explains the pin functions.
External Power
Signal
Pin 1 CD
Pin 2 RX
Pin 3 TX
Pin 4 DTR
Pin 5 GND
Pin 6 DSR*
Pin 7 RTS
Pin 8 CTS
Pin 9 RI
Note: The DSR signal on pin 6 is always asserted by the router.
18
IN/OUT
O
O
I
I
--
O
I
O
O
Multi-Tech Systems, Inc. MultiModem rCell User Guide
Serial Cable
Female Connector
