3: Server Installation

Check the Serverboard Setup

Removing the Chassis Cover and Protective Film

24
After you install the server in the rack, you will need to open the unit to make sure the serverboards
are properly installed and all the connections have been made. Before operating the server for the
first time, it is important to remove the protective film covering the top of the chassis. The removal
of this film allows for proper ventilation and cooling.
Use the following procedure for removing the chassis cover and removing the protective film as
illustrated in Figure 3-4.
1. Remove the two screws which secure the top cover onto the chassis.
2. Lift the top cover up and off the chassis.
3. Peel off the protective film covering the top cover and the top of the chassis.
4. Check that all ventilation openings on the top cover and the top of the chassis are clear and
unobstructed.
Note: To remove the system from the rack completely, depress the locking tabs on the chassis
rails (push the right-side tab down and the left-side tab up) to continue to pull the system out
past the locked position.
