IBM WebSphere DataPower 7198 Installation And User Manual page 80

Figure 29. Unlatching and rotating the front of the appliance
2. Lift the appliance off of the slide rails, as shown in Figure 30.
Figure 30. Lifting the appliance off the slide rails
60
Installation and User's Guide
a. After the front nailheads clear the latches, lift up on the rear 1 of the
appliance to level the appliance.
b. Lift the server out of the rack 2 and place it on a sturdy surface.
c. Slide the rail back in the rack.
Lift point
Lift point
