ternal selected clock source. Finally, the pulse width
measurement mode can be used to count the high or
low level duration of the external signal (TMR0/TMR1/
TMR2), and the counting is based on the internal se-
lected clock source.
In the event count or timer mode, the timer/event coun-
ter starts counting at the current contents in the
timer/event counter and ends at FFH (FFFFH). Once an
overflow occurs, the counter is reloaded from the
timer/event counter preload register, and generates an
interrupt request flag (T0F: bit 6 of the INTC0; T1F: bit 4
of the INTC1; T2F: bit 4 of the MFIC).
In the pulse width measurement mode with the values of
the T0ON/T1ON/T2ON and T0E/T1E/T2E bits equal to
²1², after the TMR0/TMR1/TMR2 has received a tran-
sient from low to high (or high to low if the T0E/T1E/T2E
bit is ²0²), it will start counting until the TMR0/TMR1/
TMR2) returns to the original level and resets the
T0ON/T1ON/T2ON. The measured result remains in
the timer/event counter even if the activated transient
occurs again. In other words, only 1-cycle measurement
can be made until the T0ON/T1ON/T2ON is set. The cy-
cle measurement will re-function as long as it receives
further transient pulse. In this operation mode, the
timer/event counter begins counting not according to
the logic level but to the transient edges. In the case of
counter overflows, the counter is reloaded from the
timer/event counter register and issues an interrupt re-
quest, as in the other two modes, i.e., event and timer
modes.
To enable the counting operation, the Timer ON bit
(T0ON/T1ON/T2ON; bit 4 of the TMR0C/TMR1C/
TMR2C) should be set to ²1². In the pulse width mea-
surement mode, the T0ON/T1ON/T2ON is automati-
cally cleared after the measurement cycle is completed.
But in the other two modes, the T0ON/T1ON/T2ON can
only be reset by instructions. The overflow of the
Timer/Event Counter 0/1 is one of the wake-up sources
and can also be applied to a PFD (Programmable Fre-
quency Divider) output at PA3 by options. Only one PFD
(PFD0 or PFD1) can be applied to PA3 by options. No
matter what the operation mode is, writing a 0 to
ET0I/ET1I/ET2I disables the related interrupt service.
When the PFD function is selected, executing ²CLR
[PA].3² instruction to enable PFD output and executing
²SET [PA].3² instruction to disable PFD output.
In the case of timer/event counter OFF condition, writing
data to the timer/event counter preload register also re-
loads that data to the timer/event counter. But if the
Rev. 1.10
HT49RU80/HT49CU80
timer/event counter is turned on, data written to the
timer/event counter is kept only in the timer/event coun-
ter preload register. The timer/event counter still contin-
ues its operation until an overflow occurs.
When the timer/event counter (reading TMR0/TMR1/
TMR2) is read, the clock is blocked to avoid errors, as
this may results in a counting error. Blocking of the clock
should be taken into account by the programmer.
It is strongly recommended to load a desired value into
the TMR0/TMR1/TMR2 register first, before turning on
the related timer/event counter, for proper operation
since the initial value of TMR0/TMR1/TMR2 is un-
known. Due to the timer/event counter scheme, the pro-
grammer should pay special attention on the instruction
to enable then disable the timer for the first time, when-
ever there is a need to use the timer/event counter func-
tion, to avoid unpredictable result. After this procedure,
the timer/event counter function can be operated nor-
mally. The following example is given, using one 8-bit
and one 16-bit width Timer (timer 0; timer 1) cascaded
into 24-bit width.
START:
mov a, 09h ; Set ET0I & EMI bits to
mov intc0, a ; enable Timer 0 and
; global interrupt
mov a, 01h ; Set ET1I bit to enable
mov intc1, a ; Timer 1 interrupt
mov a, 80h ; Set the operating mode as
mov tmr1c, a ; timer mode and select the mask
; option clock source
mov a, 0a0h ; Set the operating mode as timer
mov tmr0c, a ; mode and select the system
; clock/4
set tmr1c.4 ; Enable then disable Timer 1
clr tmr1c.4 ; for the first time
mov a, 00h ; Load a desired value into
mov tmr0, a ; the TMR0/TMR1 register
mov a, 00h ;
mov tmr1l, a ;
mov tmr1h, a ;
set tmr0c.4 ; Normal operating
set tmr1c.4 ;
END
